Parts

Specification

Order No.

MIC-M2

Frame

One-piece construction from arm to base.

MIC-M2

●

Seidentopf                                  Observation Tube

Binocular Tube, Interpupillary distance 52-75mm, 30°inclined diopter adjustable.

MS3

○

Binocular Tube, Interpupillary distance 52-75mm, 30°inclined diopter adjustable. (For WF10X/22mmeyepieces)

MS2

○

Trinocular Tube, Interpupillary distance 52-75mm, 30°inclined diopter adjustable.

MT3

●

Trinocular Tube, Interpupillary distance 52-75mm, 30°inclined diopter adjustable. (For WF10X/22mmeyepieces)

MT2

○

Eyepieces

WF10X/20mmPlan Eyepiece, High eye-point up to21mm

E1020PB

●●

WF10X/22mmPlan Eyepiece, High eye-point up to21mm

E1022PC

○○

WF10X/18mmReticule Eyepiece, High eye-point up to21mm

E1018RA

●

WF10X/20mmReticule Eyepiece, High eye-point up to21mm

E1020RA

○

Objectives

4X Infinity Plan Objectives

WM-P4A

○

10X Infinity Long WD Plan Objectives

WM-L10A

●

20 X Infinity Long WD Plan Objectives(S)

WM-L20A

●

50X Infinity Long WD Plan Objectives(S)

WM-P50A

●

80 X Infinity Long WD Plan Objectives(S)

WM-P80B

●

100X Infinity Plan Objectives(S)/(Oil)

WM-P100A

○

Stage

Mechanical Stage, 180mmx155mm; movement range: 80mmx50mm; with low-positioned X/Y coaxial control knob.

ZT5

●

Drop specimen holder(φ110)

ZT5-1000

●

Specimen holder

ZT5-2000

●●

Revolving Nosepiece

Quintuple Revolving Nosepiece

ZQ580A

●

Illumination

6V30W halogen lamphouse

SGJ1-3000

●

Reflected Light Illuminator

JX10

●

6V30W Osram halogen bulb

BZ-0022C

●

6V30W Power supply for halogen lamphouse

DYX1

●

250V/3.15AΦ5X20 fuse

BZ-0023

●●●

Blue filter(φ32)

LA1-1000

●

Green filter(φ32)

LU1-1000

●

Yellow filter(φ32)

LH1-1000

●

Polarizing Kits

Analyzer Kits

PY9

●

Polarizer Kits

PQ9

●

C-Mount

0.5XC-Mount

SX2

○

0.25XC-Mount

SX4

○

1XC-Mount

SX3

●

Others

Micrometer(1/100mm)

OMMM

○

Φ1.5mm Allen Screw Driver

BZ3-0018

●

φ2mm Allen Screw Driver

BZ2-0018

●

Φ3mm Allen Screw Driver

BZ1-0018A

●

Power cord

BZ-0021

●

Connector of Lamphouse

SG11-5000

●

Dust Cover

BZ1-0014

●
