2. With large move range mechanical stages, can move quickly and slowly.
3. Coaxial coarse/fine focus system, with tension adjustable and up stop, minimum division of fine focusing: 2μm.
4. 6V 20W Halogen lamp, brightness control.
|
Model |
XYX-M201 |
XYX-M201A |
|
Eyepiece |
Wide field WF10X(18mm) |
|
|
Objective |
Plan achromatic objectives with long working distance (no cover glass) PL 5X/0.12 |
|
|
Plan achromatic objectives with long working distance (no cover glass) PL L10X/0.25 |
||
|
Plan achromatic objectives with long working distance (no cover glass) PL L20X/0.40 |
||
|
Plan achromatic objectives with long working distance (no cover glass) PL L40X/0.60 |
||
|
Plan achromatic objectives with long working distance (no cover glass) PL L80X/0.80 |
||
|
Eyepieces tube |
Trinocular, Inclination of 30˚, (Analyzer with field diaphragm to switch) |
|
|
Vertical illumination unit |
6V 20w, halogen lamp, adjustable brightness |
|
|
Vertical illumination with field diaphragm, aperture diaphragm and polarizer,(Y,B,G)filter and frosted filter |
||
|
Focus system |
Vertical adjustable, Coaxial coarse/fine focus system, with tensional adjustable and up stop, minimum division of fine focusing2μm. |
|
|
Nosepiece |
Quintuple(Frontward ball bearing inner locating) |
|
|
Stage |
Three layer mechanical Size:250mmX230mm,movingrange:154mmX154mm |
Three layer mechanical Size:280mmX270mm,movingrange:204mmX204mm |
Optional accessories
|
Name |
Sort/Technique parameter |
NO. |
|
Eyepiece |
Wide field WF16X(11mm) |
1051016 |
|
Dividing 10X(18mm) 0.1mm/Div |
1021010 |
|
|
Objective |
Plan achromatic objectives with long working distance (no cover glass) PL L 50X/0.70 |
2250150 |
|
Plan achromatic objectives with long working distance (no cover glass) PL L 60X/0.75 (Spring) |
2250160 |
|
|
Plan achromatic objectives with long working distance (no cover glass) PL L 100X/0.85 (Spring) |
2250111 |
|
|
Plan achromatic objectives (no cover glass) PL 100X/1.25 (Spring, oil) |
2240111 |
|
|
CCD adapter |
0.4X |
810001 |
|
0.5X |
810004 |
|
|
1X |
810002 |
|
|
0.5X with dividing0.1mm/Div |
810003 |
|
|
Camera |
DV-1 With USB & video output |
800001 |
|
DV-2 With USB output |
800003 |
|
|
DV-3 With video output |
800005 |
|
|
Photo unit |
2.5X/4X Change over photograph attachment with 10X viewing eyepiece |
840001 |
|
4X Focusing photograph attachment |
840002 |
|
|
MD Adapter |
840003 |
|
|
PK Adapter |
840004 |
|
|
Digital camera adapter |
CANON(A610,A620,A630,A640) |
820001 |
