NY-5R

NY-5T/R

Optical System

Infinite optical system

●

●

Extra Wide Field Eyepiece

EW10×/20

●

●

EW10×/20 Eyepiece with scale of cross hair

●

●

EW15×/16

○

○

EW20×/12

○

○

Infinite Plan Achromatic Objective

5×/0.12/∞/- (BF/DF)        LWD10mm

●

●

10×/0.25/∞/-(BF/DF)       LWD10mm

●

●

20×/0.4/∞/0(BF/DF)         LWD5mm

●

●

50×/0.75/∞/0(BF/DF)       LWD1.3mm

●

●

100×/0.90(Dry)/∞/0(BF)   LWD0.7mm

●

●

40×/0.65/∞/0.17(BF)        WD0.6mm

●

100×/1.25/∞/0.17(BF)      WD0.16mm

●

Viewing Head

Siedentopf binocular viewing head, inclined at 30°

●

●

Siedentopf trinocular viewing head, inclined at 30°

○

○

Kohler Incident Light

12V/50W Halogen light, Center and brightness adjustable

●

●

12V/20W Halogen light, Center and brightness adjustable

●

Polarizer and analyzer

●

●

DIC

○

○

Green, Blue, Yellow, Gray and ground glass

●

●

Focusing

Coaxial coarse and fine adjustment, fine division 2μm, moving range30mm

●

●

Nosepiece

Backward quintuple nosepiece

●

●

Stage

Double layer mechanical stage 216×150mm, Moving range78mm×54mm

●

Double layer mechanical stage 186×138mm, Moving range78mm×54mm

●

Accessories

Specimen Presser

○

○

Photo attachment

○

○

Micrometer scale0.01mm

●

●
