Items

Specification

O-M2

Eyepiece

WF10×-18mm

●

Reticule Eyepiece WF 10×-18 mm(0.1mm)

●

WF5×

○

WF12.5×

○

WF16×

○

Infinity Plan Objective

(no cover glass)

5×/0.11

W.D=12.10mm

●

10×/0.25

W.D=4.75mm

●

20×/ 0.4 (S)

W.D=2.14mm

○

40×/0.65 (S)

W.D=0.45mm

○

Long Working Distance

Infinity Plan Objective

(no cover glass)

20×/0.4 (S)

W.D=8.35mm

○

40×/0.65 (S)

W.D=3.90mm

●

50×/0.7(S)

W.D=1.95mm

○

80×/0.8 (S)

W.D=0.85mm

○

Seidentopf Binocular Head

Inclined 30°,Rotatable 360°,

Interpupilary Distance:  50-75mm

●

Seidentopf Trinocular Head

Inclined 30°,Rotatable 360°,

Interpupilary Distance: 50-75mm

Light Distribution: 80:20

○

Nosepiece

Quadplex

●

Mechanical Stage

Stage Size: 200×140mm, Travel :76mm×52mm

Coaxial Coarse and Fine Focusing Knobs

●

Reflection  Illumination

6V/20W Halogen Lamp

●

Filter

Five-hole filter unit(blue, green, amber, grey，empty)

●

C-mount

1×

○

0.5× （Focus Adjustable）

○
