X-OF2 Fluorescence Microscope Outfits
|
Items |
Specification |
X-OF2 |
|
Eyepiece |
WF 10X-18mm |
●● |
|
WF 10X-20mm |
○○ |
|
|
WF16X-13mm |
○○ |
|
|
WF 10X-18 mm(Reticule0.1mm) |
○ |
|
|
Infinity E-Plan Objectives |
Plan 4X |
● |
|
Plan 10X |
● |
|
|
Plan 20X (S) |
○ |
|
|
Plan 40X (S) |
● |
|
|
Plan 100X (Oil) (S) |
● |
|
|
Main Body |
|
● |
|
Fluorescence Attachment |
Epi Fluorescence Illumination unit (B,G) |
● |
|
100W Mercury Lamp House |
● |
|
|
100W Mercury Power House |
● |
|
|
Seidentopf Binocular Head |
Inclined 30°, Rotatable 360°, Interpupilary Distance 50-75mm |
○ |
|
Trinocular Head |
Inclined
30°, |
● |
|
Quintuple Nosepiece |
|
● |
|
Mechanical Stage |
Travel:
50mmX70mm |
● |
|
Condenser |
Abbe N.A.
1.25 |
● |
|
Koehler Illumination |
6V/20W Halogen Lamp |
● |
|
6V/30W Halogen Lamp |
○ |
|
|
Filter |
Blue |
● |
|
|
0.47X （Focus adjustable） |
○ |
|
1X |
○ |
|
|
Digital Camera Adaptor |
○ |
|
Note: “●” in the table is standard attachment. “○” is optional accessories.
Design
change: To keep pace with technological advances, we have reserved the right to
make design modification and changes without notice.
