Order NO. |
Items |
XDS—2 |
EPl0a |
Eyepiece WFl0/018mm |
●● |
EPl6a |
Eyepiece WFl6X/010mm |
●● |
EPrl0b |
Plan Article Eyepiece PFl0×/~18mm |
○ |
B—OLPrl0 |
LWD Plan Achromatic Objective 10×/0.25 160/1.5 WD.=7.9mm |
● |
B—OLPr25 |
LWD Plan Achromatic Objective 25×/0.40 160/1.5 WD.=5mm |
● |
B—OLPr40 |
LWD Plan Achromatic Objective 40×/0.65 160/1.5 WD.=3mm |
● |
B—OLPprl0 |
LWD Plan Positive Phase Objective 10×/0.25 160/1.5 WD.=7.9mm |
○ |
B—OLPpr25 |
LWD Plan Positive Phase Objective 25×/0.40 160/1.5 WD.=5mnl |
● |
B—OLPpr40 |
LWD Plan Positive Phase Objective 40×/0.65 160/1.5 WD.=3mm |
○ |
TBR03 |
Seidentopf Binocular Head (Inclined 45·) |
● |
Main Body Including Left & Right Supporting Arm.4 Pieces Of Allen Screws&One Wrench) |
● |
|
CU02—4 |
Blue Filter |
● |
CU02—5 |
Green Filter |
● |
CU02—6 |
Amber Filter |
● |
CU02—7 |
Grey Filter |
● |
12X-3 |
Stage (On The Main Body) |
● |
33X—4 |
Set For Stage Insert Plate |
● |
9J—8 |
Stage insert Plate (III) |
● |
9J—9 |
Stage insert Plate (IV) |
● |
CL02 |
Stage Clips |
● ● |
LS08.3 |
Annular Sliding Set |
● |
LS08.5—27 |
Phase Contrast Annular 10X |
○ |
LS08.6—29 |
Phase Contrast Annular 25X |
● |
LS08.7—3 1 |
Phase Contrast Annular 40X |
○ |
|
Halogen Tungsten Lamp 6V/20W |
●●● |
7X.5.1 |
Cultural Vessel Bottom Thickness1.5mm |
● |
7X.5.2 |
Cultural Flask (Bottom Thickness1.5mm) |
● |
DV03 |
Adapter For Digital Camera (Available ForOlympusC5060) |
○ |
Note: “●” in the table is standard attachment. “○” is optional accessories.
Design change: To keep pace with technological
advances, we have reserved the right to
make design modification and changes
without notice.
