· UCIS Infinity Independent Achromatic Optical System
· Seidentopf binocular viewing head, inclined 30º, 52-75mminterpupillary distance settings, ±5 º Diopter adjustment
· WF10X plan eyepieces,20mmfield of view, high eye point up to21mm
· Quintuple nosepiece inward facing with positive click stops
· Infinity long work distance plan Achromatic 10X, 20X, 40X and Infinity long work distance phase-contrast 20X objectives
· Mechanical stage, 180mmX155mm, move range 80mmX50mm
· N.A. 0.30Abbe condenser with iris diaphragm, with phase-contrast slide, long work distance72mm
· Coaxial coarse and fine focus mechanism with markings. Fine focus sensitivity0.001mm
· 6 volt 30 watt halogen illumination
· Dust cover, power cord
· 110V-240V Wide voltage
|
Order No. |
Specification |
P-I2 |
|
P-I2 |
Microscope Frame |
● |
|
MS3 |
Binocular Tube, Interpupillary distance 52-75mm, 30°inclined diopter adjustable. |
○ |
|
MT3 |
Trinocular Tube, Interpupillary distance 52-75mm, 30°inclined diopter adjustable. |
● |
|
E1020PB |
WF10X/20mmPlan Eyepiece, High eye-point up to21mm |
●● |
|
E1018RA |
WF10X/18mmReticule Eyepiece, High eye-point up to21mm |
○ |
|
DZ1 |
Centering Telescope |
● |
|
E1613PA |
16X/13mmEyepiece |
○○ |
|
MS2 |
Binocular Tube, Interpupillary distance 52-75mm, 30°inclined diopter adjustable. (For WF10X/22mmeyepieces) |
○ |
|
MT2 |
Trinocular Tube, Interpupillary distance 52-75mm, 30°inclined diopter adjustable. (For WF10X/22mmeyepieces) |
○ |
|
E1022PC |
WF10X/22mmPlan Eyepiece, High eye-point up to21mm |
○○ |
|
E1020RA |
WF10X/20mmReticule Eyepiece, High eye-point up to21mm |
○ |
|
DZ1 |
Centering Telescope |
○ |
|
E1613PA |
16X/13mmEyepiece |
○○ |
|
WB-P4C |
4X Infinity Long WD Plan Objectives |
○ |
|
WB-L10B |
10X Infinity Long WD Plan Objectives |
● |
|
WB-L20B |
20 X Infinity Long WD Plan Objectives |
● |
|
WB-L40B |
40X Infinity Long WD Plan Objectives |
● |
|
WB-L60B |
60 X Infinity Long WD Plan Objectives |
○ |
|
WB-LPHp10B |
10X Infinity Plan Phase-Contrast Positive Objectives |
○ |
|
WB-LPHp20B |
20X Infinity Plan Phase-Contrast Positive Objectives |
● |
|
WB-LPHp40B |
40X Infinity Plan Phase-Contrast Positive Objectives |
○ |
|
WB-LPHn10B |
10X Infinity Plan Phase-Contrast Negative Objectives |
○ |
|
WB-LPHn20B |
20X Infinity Plan Phase-Contrast Negative Objectives |
○ |
|
WB-LPHn40B |
40X Infinity Plan Phase-Contrast Negative Objectives |
○ |
|
ZT5 |
Fixed Stage, 240mmX180mm |
○ |
|
ZT5-1000 |
Drop specimen holder(φ110) |
○ |
|
ZT5-2000 |
Specimen holder |
○ |
|
ZT5A |
Mechanical Stage, 180mmx155mm; movement range: 80mmx50mm; with low-positioned X/Y coaxial control knob. |
● |
|
ZT5-1000 |
Drop specimen holder(φ110) |
● |
|
ZT5-2000 |
Specimen holder |
● |
|
ZQ580A |
Quintuple Revolving Nosepiece |
● |
|
SGJ5 |
Ultra long WD Condenser |
● |
|
PCB-LPHA |
Phase-contrast Slide |
● |
|
SGJ1-3000 |
6V30W Halogen Lamp House |
● |
|
SGJ5-0023 |
Filter Holder |
● |
|
LA1-0011 |
Blue filter(φ34) |
● |
|
LU1-0011 |
Green filter(φ34) |
● |
|
LH1-0011 |
Yellow filter(φ34) |
● |
|
SX2 |
0.5X C-Mount |
○ |
|
SX3 |
1X C-Mount |
○ |
|
SX4 |
0.25X C-Mount |
○ |
|
BZ-0022C |
6V30W Osram Halogen Bulb |
● |
|
DQ5 |
Electrics for 6V30W Halogen |
● |
|
BZ-0023 |
250V/3.15AΦ5X20 Fuse |
●●● |
Note: “●” in the table is standard attachment. “○” is optional accessories.
Design
change: To keep pace with technological advances, we have reserved the right to
make design modification and changes without notice.
