Standard Configuration
|
Model |
XSL-79A |
XSL-79B |
|
Eyepiece |
WF10X(18mm) |
|
|
Objective |
Achromatic 4X/0.10 |
Achromatic 4X/0.10 |
|
Achromatic 10X/0.25 |
Achromatic 10X/0.25 |
|
|
Achromatic 40X/0.65(Spring) |
Achromatic 40X/0.65(Spring) |
|
|
|
Achromatic100X/1.25(Spring oil) |
|
|
Eyepiece tube |
Monocular,360˚ rotatable (Inclination of 45˚) |
|
|
Nosepiece |
Triple(Frontward ball bearing outer locating) |
Quadruple (Frontward ball bearing outer locating) |
|
Focus system |
Coaxial coarse/fine focus system. Minimum division of fine focusing: 4μm |
|
|
Stage |
Fixed(Size:120mmX120mm, With five holes fixed iris diaphragm) |
Double-layer mechanical, size:125mmX115mm, move range:70mmX30mm |
|
Abbe condenser |
|
Rack &pinion adjustment |
|
Collector |
For LED lamp |
|
|
Light source |
LED High brightness white LED lamp |
|
Optional accessories
|
Name |
Sort/Technique parameter |
NO. |
||
|
Eyepiece |
Wide field WF16X(11mm) |
1051016 |
||
|
Point 10X(18mm) |
1043010 |
|||
|
Stage |
Fixed(Size:120mmX120mm, With single lens and iris diaphragm) |
040001 |
||
|
Fixed(Size:120mmX120mm, with slide moving holder and Abbe condenser) |
040004 |
|||
|
Filter |
Blue filter |
115001 |
||
|
Green filter |
115002 |
|||
|
Yellow filter |
115003 |
|||
|
Frosted filter |
115004 |
|||
|
Collector |
For Fluorescent and Halogen lamp |
060002 |
||
|
For Incandescent lamp |
060004 |
|||
|
Light source |
High brightness white LED lamp |
With adapter |
073011 |
|
|
High brightness white LED lamp |
With adapter and charge batteries |
073012 |
||
|
Halogen lamp |
12V 20W |
070019 |
||
|
Fluorescent lamp |
110V/220V, 5W Can be choose |
071006 |
||
|
Incandescent lamp |
220V/110V, 20W Can be choose |
072004 |
||
|
Camera |
Photography |
USB Output |
1096001 |
|
|
VIDEO Output |
1108001 |
|||
|
Adapter (For LED illumination) |
Input: 230V50/60HZ Output: 9V 500mA |
101001 |
||
|
Input: 110V50/60HZ Output: 9V 500mA |
101002 |
|||
|
|
||||
