XSL-32 series biological microscopes are equipped with infinity plan achromatic objectives and wide field eyepieces. They have beautiful sculpt and provide clear image, wide field, convenience operation. They can be used for biology medicine agriculture and industry area widely. They are the ideal instrument in medical treatment, teaching demonstration and scientific research.
Standard Configuration
|
Model |
XSL-32 |
|
|
Eyepiece |
WF10X(22mm) |
|
|
Objective |
Infinity plan achromatic objective |
|
|
PL 4X/0.10(Work distance)：19.8 mm |
||
|
PL 10X/0.25(Work distance)：5.0mm |
||
|
PL 40X/0.65(Spring)(Work distance)：0.66 mm |
||
|
PL 100X/1.25(Spring, oil)(Work distance)： 0.36mm |
||
|
Eyepiece tube |
XSL-32HBG |
Binocular (Inclination of 30˚) |
|
XSL-32HTG |
Trinocular(Inclination of 30˚) |
|
|
Focus system |
Coaxial coarse/fine focus, with tension adjustable and up stop minimum division of fine focusing: 2μm. |
|
|
Nosepiece |
Quadruple(Backward ball bearing inner locating) |
|
|
Stage |
Double layer mechanical (Size:210mmX140mm,Move range: 75mmX50mm) |
|
|
Abbe condenser |
N.A.1.25Rack & pinion adjustable |
|
|
Filter |
Blue filter |
|
|
Frosted filter |
||
|
Collector |
For halogen lamp(With field diaphragm ) |
|
|
Light source |
6V 30W Halogen lamp with brightness control |
|
Optional
accessories
|
Name |
Sort/Technique parameter |
NO. |
||
|
Eyepiece |
Dividing eyepiece(field number:22mm) 0.10mm/Div |
1122010
|
||
|
Objective |
Infinity plan achromatic objective |
|
||
|
PL 20X/0.40(Work distance)：8.8 mm |
2060120 |
|||
|
PL 60X/0.85(Work distance)：0.25mm |
2060160 |
|||
|
Nosepiece |
Quintuple(Backward ball bearing inner locating) |
032002 |
||
|
Filter |
Green filter |
115002 |
||
|
Yellow filter |
115003 |
|||
|
Condenser |
Dark field |
Dry type |
051001 |
|
|
Immersion type |
051002 |
|||
|
Phase contrast unit |
Eyepiece |
Centering telescope |
110002 |
|
|
Objectives |
Infinity phase contrast plan achromatic 10X/0.25 PHP |
2470110 |
||
|
Infinity phase contrast plan achromatic 20X/0.40 PHP |
2470120 |
|||
|
Infinity phase contrast plan achromatic 40X/0.65 PHP(Spring) |
2470140 |
|||
|
Infinity phase contrast plan achromatic 100X/1.25 PHP(Spring, oil) |
2470111 |
|||
|
(PHP Turnplate phase contrast condenser |
052001 |
|||
|
(PHP) Turnplate phase contrast condenser |
052004 |
|||
|
Flashboard phase contrast condenser |
052002 |
|||
|
Pull board phase contrast condenser |
052003 |
|||
|
CCD adapter |
0.4X |
810001 |
||
|
0.5X |
810004 |
|||
|
1X |
810002 |
|||
|
0.5X with dividing0.1mm/Div |
810003 |
|||
|
Camera |
DV-1 Video output£¨380/520 TV line£© USB output £¨0.42 Mpixel£© |
800001 |
||
|
DV-2 With USB output £¨1.3M,2.0M,3.0Mpixel£© |
800003 |
|||
|
DV-3 With video output£¨380/520 TV line£© |
800005 |
|||
|
Photo unit |
2.5X/4X Change over photograph attachment with 10X viewing eyepiece |
840001 |
||
|
4X Focusing photograph attachment |
840002 |
|||
|
MD adapter |
840003 |
|||
|
PK adapter |
840004 |
|||
|
Digital camera adapter |
CANON(A570,A610,A620,A630,A640,A650,EF) NIKON( F) |
820001 |
||
|
Facility polarize
|
Polarizer |
360° rotatable stage |
111001 |
|
|
Analyzer |
Sliding type |
111105 |
||
|
|
||||
