Standard Configuration
|
Model |
XSL-20 |
|
Eyepiece |
WF10X(20mm) |
|
Objective |
Plan achromatic PL 4X/0.10 |
|
Plan achromatic PL 10X/0.25 |
|
|
Plan achromatic PL 20X/0.40 |
|
|
Plan achromatic PL 40X/0.65(Spring) |
|
|
Plan achromatic PL 100X/1.25(Spring, oil) |
|
|
Eyepiece tube |
Binocular(Inclination of 30˚) |
|
Focus system |
Coaxial coarse/fine focus, with tensional adjustable and up stop minimum division of fine focusing: 2μm. |
|
Nosepiece |
Quintuple(Backward ball bearing inner locating) |
|
Stage |
Double layer mechanical (Size:160mmX140mm, Move range: 75mmX50mm) |
|
Abbe condenser |
N.A.1.25Rack & pinion adjustable |
|
Filter |
Blue filter |
|
Frosted filter |
|
|
Collector |
For halogen lamp |
|
Light source |
12V 50W Halogen lamp with brightness control. |
Optional accessories
|
Name |
Sort/Technique parameter |
NO. |
|
|
Eyepiece |
Wide field WF16X(11mm) |
1051016 |
|
|
Dividing 10X(18mm) 0.1mm/Div |
1121010 |
||
|
Eyepiece tube |
Trinocular (Inclination of 30˚) |
012005 |
|
|
Filter |
Green filter |
115002 |
|
|
Yellow filter |
115003 |
||
|
Nosepiece |
Quadruple(Backward ball bearing inner locating) |
031005 |
|
|
Condenser |
Dark field |
Dry |
051001 |
|
Immersion |
051002 |
||
|
Phase contrast unit |
Eyepiece |
Centering telescope |
110001 |
|
Objectives |
Phase contrast plan achromatic 10X/0.25 PHP |
2420110 |
|
|
Phase contrast plan achromatic 20X/0.40 PHP(Spring) |
2420120 |
||
|
Phase contrast plan achromatic 40X/0.65 PHP(Spring) |
2420140 |
||
|
Phase contrast plan achromatic 100X/1.25 PHP(Spring, oil) |
2420111 |
||
|
(PHP) Turnplate phase contrast condenser |
052001 |
||
|
(PHP) Turnplate phase contrast condenser |
052004 |
||
|
Flashboard phase contrast condenser |
052002 |
||
|
Pull board phase contrast condenser |
052003 |
||
|
Infinity optical system |
Eyepiece tube |
Binocular(Inclination of 30˚) |
011103 |
|
Trinocular(Inclination of 30˚) |
012103 |
||
|
Eyepiece |
Centering telescope |
110002 |
|
|
Objectives |
Infinity plan achromatic 4X/0.10 |
2060104 |
|
|
Infinity plan achromatic 10X/0.25 |
2060110 |
||
|
Infinity plan achromatic 20X/0.40 |
2060120 |
||
|
Infinity plan achromatic 40X/0.65(Spring) |
2060140 |
||
|
Infinity plan achromatic 100X/1.25(Spring, oil) |
2060111 |
||
|
Infinity phase contrast plan achromatic 10X/0.25 PHP |
2470110 |
||
|
Infinity phase contrast plan achromatic 20X/0.40 PHP |
2470120 |
||
|
Infinity phase contrast plan achromatic 40X/0.65 PHP(Spring) |
2470140 |
||
|
Infinity phase contrast plan achromatic 100X/1.25 PHP(Spring, Oil) |
2470111 |
||
|
CCD adapter |
0.4X |
810001 |
|
|
0.5X |
810004 |
||
|
1X |
810002 |
||
|
0.5X with dividing0.1mm/Div |
810003 |
||
|
Camera |
DV-1(With USB & video output() |
800001 |
|
|
DV-2(With USB output) |
800003 |
||
|
DV-3(With video output) |
800005 |
||
|
Digital camera adapter |
CANON Digital camera adapter(A610,A620,A630,A640) |
820001 |
|
|
Photograph unit |
2.5X/4X Change over photograph attachment with 10X viewing eyepiece |
840001 |
|
|
4X Focusing photograph attachment |
840002 |
||
|
MD Adapter |
840003 |
||
|
PK Adapter |
840004 |
||
|
Facility polarize
|
Polarizer(360° rotatable stage) |
111001 |
|
|
Analyzer |
111101 |
||
