XSZ-E30 series biological microscope
•Infinity color corrected optical system with high quality micro-technique presents superexcellent micro-image at any observation.
•Wide-field high eye-point eyepieces and plan achromatic objectives make the effect of fluorescence observation more perfect.
•Outstanding appearance design and ergonomics structure design, long time use without feeling tired.
•With the design of security lock and safe limits, it is much more secure, stable. And can be kept for long.
•Various microscopic examinations can be fulfilled, such as bright-field, dark-field, phase contrast, fluorescence, simple polarizing and so on.
specifications：
|
Model |
XSZ-E30 |
|
Optical system |
Infinity corrected Achromatic optical system |
|
Eyepiece |
PL10X/20T High eye-point wide-field plan eyepiece, field of view:20mm,effective exit pupil distance:19mm, diopter +/-5 adjustable |
|
PL10X/22T High eye-point wide-field plan eyepiece, field of view:20mm, effective exit pupil distance:19mm, diopter +/-5 adjustable |
|
|
0bjective |
Infinity plan achromatic objective 4X、10X、20X、40X、100X |
|
Infinity phase contrast objective 10X、20X、40X、100X |
|
|
Infinity semi-achromatic fluorescence objective 4X、10X、20X、40X、100X |
|
|
Viewing head |
30°gemel binocular viewing head with 360° rotatable eyepiece tube, interpupillary adjustable distance: 50-75mm |
|
30°gemel trinocular viewing head with 360° rotatable eyepiece tube, interpupillary adjustable distance: 50-75mm, fixed spectroscopic ratio R:T=80%: 20% |
|
|
30°gemel trinocular viewing head(dedicated for fluorescence) with 360° rotatable eyepiece tube, interpupillary adjustable distance: 50-75mm, fixed spectroscopic ratio R:T= 50%:50% |
|
|
30°gemel digital viewing head(with 3.0/5.0 mega pixels) |
|
|
Nosepiece |
Reversed quadruple nosepiece |
|
Reversed quintuple nosepiece |
|
|
Stage |
150x140mmmechanical stage with underhand, moving range: 76x50mm, precision:0.1mm, with damping clips |
|
Condenser |
N.A.1.25Koehler illuminator condenser(with socket for phase contrast and dark-field accessories) |
|
Focus adjustment |
Integrated all-metal high-pressure die-casting (HPDC) body, precision transmission mechanism with pinion and rack. Coarse focusing scope:30mm, with tightness adjustment and place limit set, fine adjustable precision:0.002mm |
|
LED fluorescent reflected illumination |
UV2 ultraviolet long-pass type LED module, with intensity adjusting knob, and switch knob for bright field and fluorescence, central wavelength:365mm |
|
B4 LED fluorescence module dedicated for TB, with intensity adjusting knob, and switch knob for bright field and fluorescence, central wavelength:455mm |
|
|
B1 band-pass type fluorescence module, with intensity adjusting knob, and switch knob for bright field and fluorescence, central wavelength:470mm |
|
|
G1 band-pass type LED fluorescence module, with intensity adjusting knob, and switch knob for bright field and fluorescence, central wavelength:560mm |
|
|
Other various LED modules for option, which can be custom-tailor according to the needs of clinical diagnosis. |
|
|
Mercury reflected illumination |
Mercury reflected fluorescent illuminator, 100W mercury lamp house, 100W DC mercury bulb(OSRAM/domestic) |
|
Transmitted illumination |
100V-240V_AC50/60Hz wide range voltage, single high brightness 3W LED(predetermine filament center), intensity continuously adjustable |
|
100V-240V_AC50/60Hz wide range voltage, Philips 6V/30W halogen bulbs(predetermined filament center), intensity continuously adjustable |
|
|
External battery supply |
Power supply for at least 8 hours, rechargeable |
|
Camera accessory |
1xCTV/0.5xCTV/0.35xCTV、3.2x photo ocular 、photo tube(with PK mount or MD mount), C-mount and relay lens |
|
Other optional |
Dark-field accessory, phase contrast accessory, polarizer/analyzer |
