MIC TECH’S G series GIGE gigabit Ethernet CMOS industrial camer as with external trigger function, adopt RJ45 network interface. Image data transmission distance and speed can reach 100m@1GBPS in single cable, compatible with MB network.With built-in image buffer and image processing module
|
Model No |
Sensor |
Sensor |
Color |
Sensor |
Pixel |
Shutter |
Pixel |
Resolution |
Data |
Frame |
Lens |
|
G036M |
CMOS |
MT9V32 |
Mono |
1/3” |
6μm |
Global |
0.36MP |
752 x 480 |
GIGE |
114FPS |
C/ CS |
|
G036 |
CMOS |
MT9V32 |
Color |
1/3” |
6μm |
Global |
0.36MP |
752 x 480 |
GIGE |
114FPS |
C/ CS |
|
G120M |
CMOS |
AR0134 |
Mono |
1/3” |
3.75μm |
Global |
1.2MP |
1280 x 960 |
GIGE |
54FPS |
C/ CS |
|
G120 |
CMOS |
AR0134 |
Color |
1/3” |
3.75μm |
Global |
1.2MP |
1280 x 960 |
GIGE |
54FPS |
C/ CS |
|
GM133M |
CMOS |
MT9M001 |
Mono |
1/2” |
5.2μm x 5.2μm |
Rolling |
1.3MP |
1280 x 1024 |
GIGE |
30FPS |
C / CS |
|
G200M |
CMOS |
EV76C570 |
Mono |
1/1.8” |
4.5μm |
Global |
2MP |
1600 x 1200 |
GIGE |
52FPS |
C/ CS |
|
G200 |
CMOS |
EV76C570 |
Color |
1/1.8” |
4.5μm |
Global |
2MP |
1600 x 1200 |
GIGE |
52FPS |
C/ CS |
|
GM503M |
CMOS |
MT9P031 |
Mono |
1/2.5” |
2.2μm x 2.2μm |
Rolling |
5.0MP |
2592 x 1944 |
GIGE |
14FPS |
C/ CS |
|
GM503 |
CMOS |
MT9P006 |
Color |
1/2.5” |
2.2μm x 2.2μm |
Rolling |
5.0MP |
2592 x 1944 |
GIGE |
14FPS |
C/ CS |
|
GM1003 |
CMOS |
MT9J003 |
Color |
1/2.3” |
1.67μm x 1.67μm |
Rolling |
10MP |
3664 x 2748 |
GIGE |
8FPS |
C/ CS |
|
Model No |
G036M-H |
|
Pixels |
0.36MP ( Mono) |
|
Sensor |
MT9V032 |
|
Sensor Size |
1/3" |
|
Photosurface Size |
4.51mm(H) x 2.88mm(V) |
|
Pixel Size |
6.0μm x 6.0μm |
|
Resolution/ |
752 x 480：114FPS |
|
640 x 480（ROI）：74FPS |
|
|
320 x 240（ROI）：142FPS |
|
|
Any Area（ROI） |
|
|
Shutter |
Global Shutter |
|
Exposure Time |
109μs ～ 300ms |
|
Sensitivity |
4.8V/Lux-sec |
|
Spectral Range |
380nm ～ 1000nm |
|
SNR |
37.3dB |
|
Dynamic Range |
>55dB |
|
Oprating Mode |
Continuous Output / Software Trigger / Hardware Trigger |
|
Scanning type |
Progressive Scan |
|
Exposure |
Manual / Auto / Area |
|
White Balance |
Manual / One-Time / Auto / Area (only for color) |
|
Image processing |
GAMMA / Contrast / Black Level / Noise Reduction / 3D Noise Reduction/ Sharpness / RGB Gain/ Saturation (RGB Gain and Saturation only for color camera) |
|
Image data format |
8bit /10bit RAW |
|
Photo Format |
JPEG / BMP / PNG / RAW |
|
Built-in buffer |
32K bit |
|
Product ID |
User Defined |
|
Hardware Trigger Interface |
6 Pin Connector（1*trigger input interface (Opto-couplers isolation),1*flashlight output interface(Opto-couplers isolation)） |
|
Data Interface |
Gigabit Ethernet interface（RJ45 Connectors） |
|
Transmission Distance |
100 Meters |
|
Software Interface |
DirectShow / TWAIN |
|
Operating System |
Windows XP(32 bit) / Windows7(32 bit/64 bit) / Windows8(32 bit/64 bit) / Windows8.1(32 bit/64 bit) / Windows10(64 bit) |
|
Lens Mount |
C / CS Mount |
|
Dimension (mm) |
44mm x 44mm x 39mm （Exclude lens extended ring） |
|
Weight |
Approx. 121g |
|
Rated Voltage (V) |
9～24V（Standard 12V Power Supply） |
|
Rated power (W) |
2.5W |
|
Temperature |
Working：0～45℃ / Storage：-20℃～60℃ |
|
Humidity |
Working ：10%～90%RH（No condensation） / Storage：10%～60%RH |
|
LED Pilot light |
Lighting Once Plug / Flashing When Working |
|
Model No |
G036-H |
|
Pixels |
0.36 MP (Color) |
|
Sensor |
MT9V032 |
|
Sensor Size |
1/3" |
|
Photosurface Size |
4.51mm(H) x 2.88mm(V) |
|
Pixel Size |
6.0μm x 6.0μm |
|
Resolution/ |
752 x 480：114FPS |
|
640 x 480（ROI）：74FPS |
|
|
320 x 240（ROI）：142FPS |
|
|
Any Area（ROI） |
|
|
Shutter |
Global Shutter |
|
Exposure Time |
109μs ～ 300ms |
|
Sensitivity |
4.8V/Lux-sec |
|
Spectral Range |
380nm ～ 650nm |
|
SNR |
37.3dB |
|
Dynamic Range |
>55dB |
|
Oprating Mode |
Continuous Output / Software Trigger / Hardware Trigger |
|
Scanning type |
Progressive Scan |
|
Exposure |
Manual / Auto / Area |
|
White Balance |
Manual / One-Time / Auto / Area (only for color) |
|
Image processing |
GAMMA / Contrast / Black Level / Noise Reduction / 3D Noise Reduction/ Sharpness / RGB Gain/ Saturation (RGB Gain and Saturation only for color camera) |
|
Image data format |
8bit /10bit RAW |
|
Photo Format |
JPEG / BMP / PNG / RAW |
|
Built-in buffer |
32K bit |
|
Product ID |
User Defined |
|
Hardware Trigger Interface |
6 Pin Connector（1*trigger input interface (Opto-couplers isolation),1*flashlight output interface(Opto-couplers isolation)） |
|
Data Interface |
Gigabit Ethernet interface（RJ45 Connectors） |
|
Transmission Distance |
100 Meters |
|
Software Interface |
DirectShow / TWAIN |
|
Operating System |
Windows XP(32 bit) / Windows7(32 bit/64 bit) / Windows8(32 bit/64 bit) / Windows8.1(32 bit/64 bit) / Windows10(64 bit) |
|
Lens Mount |
C / CS Mount |
|
Dimension (mm) |
44mm x 44mm x 39mm （Exclude lens extended ring） |
|
Weight |
Approx. 121g |
|
Rated Voltage (V) |
9～24V（Standard 12V Power Supply） |
|
Rated power (W) |
2.5W |
|
Temperature |
Working：0～45℃ / Storage：-20℃～60℃ |
|
Humidity |
Working ：10%～90%RH（No condensation） / Storage：10%～60%RH |
|
LED Pilot light |
Lighting Once Plug / Flashing When Working |
|
Model No |
G120M-H |
|
Pixels |
1.2MP ( Mono) |
|
Sensor |
AR0134 |
|
Sensor Size |
1/3" |
|
Photosurface Size |
4.80mm(H) x 3.6mm(V) |
|
Pixel Size |
3.75μm x 3.75μm |
|
Resolution/ |
1280 x 960：54FPS |
|
- |
|
|
- |
|
|
Any Area（ROI） |
|
|
Shutter |
Global Shutter |
|
Exposure Time |
109μs ～ 300ms |
|
Sensitivity |
6.1V/Lux-sec |
|
Spectral Range |
380nm ～ 1100nm |
|
SNR |
38.6dB |
|
Dynamic Range |
>64dB |
|
Oprating Mode |
Continuous Output / Software Trigger / Hardware Trigger |
|
Scanning type |
Progressive Scan |
|
Exposure |
Manual / Auto / Area |
|
White Balance |
Manual / One-Time / Auto / Area (only for color) |
|
Image processing |
GAMMA / Contrast / Black Level / Noise Reduction / 3D Noise Reduction/ Sharpness / RGB Gain/ Saturation (RGB Gain and Saturation only for color camera) |
|
Image data format |
8bit /12bit RAW |
|
Photo Format |
JPEG / BMP / PNG / RAW |
|
Built-in buffer |
32K bit |
|
Product ID |
User Defined |
|
Hardware Trigger Interface |
6 Pin Connector（1*trigger input interface (Opto-couplers isolation),1*flashlight output interface(Opto-couplers isolation)） |
|
Data Interface |
Gigabit Ethernet interface（RJ45 Connectors） |
|
Transmission Distance |
100 Meters |
|
Software Interface |
DirectShow / TWAIN |
|
Operating System |
Windows XP(32 bit) / Windows7(32 bit/64 bit) / Windows8(32 bit/64 bit) / Windows8.1(32 bit/64 bit) / Windows10(64 bit) |
|
Lens Mount |
C / CS Mount |
|
Dimension (mm) |
44mm x 44mm x 39mm （Exclude lens extended ring） |
|
Weight |
Approx. 121g |
|
Rated Voltage (V) |
9～24V（Standard 12V Power Supply） |
|
Rated power (W) |
2.5W |
|
Temperature |
Working：0～45℃ / Storage：-20℃～60℃ |
|
Humidity |
Working ：10%～90%RH（No condensation） / Storage：10%～60%RH |
|
LED Pilot light |
Lighting Once Plug / Flashing When Working |
|
Model No |
G120-H |
|
Pixels |
1.2MP (Color) |
|
Sensor |
AR0134 |
|
Sensor Size |
1/3" |
|
Photosurface Size |
4.80mm(H) x 3.6mm(V) |
|
Pixel Size |
3.75μm x 3.75μm |
|
Resolution/ |
1280 x 960：54FPS |
|
- |
|
|
- |
|
|
Any Area（ROI） |
|
|
Shutter |
Global Shutter |
|
Exposure Time |
109μs ～ 300ms |
|
Sensitivity |
5.3V/Lux-sec |
|
Spectral Range |
380nm ～ 650nm |
|
SNR |
38.6dB |
|
Dynamic Range |
>64dB |
|
Oprating Mode |
Continuous Output / Software Trigger / Hardware Trigger |
|
Scanning type |
Progressive Scan |
|
Exposure |
Manual / Auto / Area |
|
White Balance |
Manual / One-Time / Auto / Area (only for color) |
|
Image processing |
GAMMA / Contrast / Black Level / Noise Reduction / 3D Noise Reduction/ Sharpness / RGB Gain/ Saturation (RGB Gain and Saturation only for color camera) |
|
Image data format |
8bit /12bit RAW |
|
Photo Format |
JPEG / BMP / PNG / RAW |
|
Built-in buffer |
32K bit |
|
Product ID |
User Defined |
|
Hardware Trigger Interface |
6 Pin Connector（1*trigger input interface (Opto-couplers isolation),1*flashlight output interface(Opto-couplers isolation)） |
|
Data Interface |
Gigabit Ethernet interface（RJ45 Connectors） |
|
Transmission Distance |
100 Meters |
|
Software Interface |
DirectShow / TWAIN |
|
Operating System |
Windows XP(32 bit) / Windows7(32 bit/64 bit) / Windows8(32 bit/64 bit) / Windows8.1(32 bit/64 bit) / Windows10(64 bit) |
|
Lens Mount |
C / CS Mount |
|
Dimension (mm) |
44mm x 44mm x 39mm （Exclude lens extended ring） |
|
Weight |
Approx. 121g |
|
Rated Voltage (V) |
9～24V（Standard 12V Power Supply） |
|
Rated power (W) |
2.5W |
|
Temperature |
Working：0～45℃ / Storage：-20℃～60℃ |
|
Humidity |
Working ：10%～90%RH（No condensation） / Storage：10%～60%RH |
|
LED Pilot light |
Lighting Once Plug / Flashing When Working |
|
Model No |
GM133M-H |
|
Pixels |
1.3MP（Mono） |
|
Sensor |
MT9M001 |
|
Sensor Size |
1/2" |
|
Maximum Resolution |
1280(H) x 1024(V) |
|
Pixel Size |
5.2μm x 5.2μm |
|
Resolution/Frame Rate |
30FPS |
|
BIN |
2 x 2 |
|
ROI |
Any Area（ROI） |
|
Shutter |
Rolling Shutter |
|
Exposure Time |
0.028ms ～ 262ms |
|
Sensitivity |
2.1V/Lux-sec |
|
Spectral Range |
380nm ～ 1000nm |
|
SNR |
45dB |
|
SNR |
68.2dB |
|
Oprating Mode |
Continuous Output / Software Trigger |
|
Built-in buffer |
32MB |
|
Exposure |
Manual / Auto / Area |
|
White Balance |
Manual / One-Time / Auto / Area (only for color camera) |
|
Image processing |
Work Speed / Image Size/ Brightness/ Exposure/ RGB Gain/GAMMA /Contrast/Saturation/Black Balance/ Sharpness /2D、3D Noise Reduction/ ( Saturation only for color camera) |
|
Image data format |
8bit /10bit RAW |
|
Built-in buffer |
32K bit |
|
Product ID |
User Defined |
|
Data Interface |
GIGE VISION（RJ45 Connectors） |
|
Transmission Distance |
100 Meters |
|
Software Interface |
GIGE Vision V1.2 / GENICAM / DirectShow / TWAIN |
|
Operating System |
Windows XP(32 bit) / Windows7(32 bit/64 bit) / Windows8(32 bit/64 bit) / Windows8.1(32 bit/64 bit) / Windows10(64 bit) |
|
Lens Mount |
C / CS Mount |
|
Dimension (mm) |
44mm x 44mm x 42mm |
|
Weight |
Approx. 150g |
|
Rated Voltage (V) |
9～24V（Standard 12V Power Supply） |
|
Rated power (W) |
< 2.5W |
|
Working Temperature |
0～50℃ |
|
Working Humidity |
10%～90%RH（No condensation） |
|
Safety Standards |
CE ROHS |
|
Model No |
G200M-H |
|
Pixels |
2MP ( Mono) |
|
Sensor |
EV76C570 |
|
Sensor Size |
1/1.8" |
|
Photosurface Size |
7.2mm(H) x 5.4mm(V) |
|
Pixel Size |
4.5μm x 4.5μm |
|
Resolution/ |
1600 x 1200：52FPS |
|
- |
|
|
- |
|
|
Any Area（ROI） |
|
|
Shutter |
Global Shutter |
|
Exposure Time |
20μs ～ 300ms |
|
Sensitivity |
- |
|
Spectral Range |
380nm ～ 1000nm |
|
SNR |
39dB |
|
Dynamic Range |
>52dB |
|
Oprating Mode |
Continuous Output / Software Trigger / Hardware Trigger |
|
Scanning type |
Progressive Scan |
|
Exposure |
Manual / Auto / Area |
|
White Balance |
Manual / One-Time / Auto / Area (only for color) |
|
Image processing |
GAMMA / Contrast / Black Level / Noise Reduction / 3D Noise Reduction/ Sharpness / RGB Gain/ Saturation (RGB Gain and Saturation only for color camera) |
|
Image data format |
8bit /10bit RAW |
|
Photo Format |
JPEG / BMP / PNG / RAW |
|
Built-in buffer |
32K bit |
|
Product ID |
User Defined |
|
Model No |
G200-H |
|
Pixels |
2MP ( Color) |
|
Sensor |
EV76C570 |
|
Sensor Size |
1/1.8" |
|
Photosurface Size |
7.2mm(H) x 5.4mm(V) |
|
Pixel Size |
4.5μm x 4.5μm |
|
Resolution/ |
1600 x 1200：52FPS |
|
- |
|
|
- |
|
|
Any Area（ROI） |
|
|
Shutter |
Global Shutter |
|
Exposure Time |
20μs ～ 300ms |
|
Sensitivity |
- |
|
Spectral Range |
380nm ～ 650nm |
|
SNR |
39dB |
|
Dynamic Range |
>52dB |
|
Oprating Mode |
Continuous Output / Software Trigger / Hardware Trigger |
|
Scanning type |
Progressive Scan |
|
Exposure |
Manual / Auto / Area |
|
White Balance |
Manual / One-Time / Auto / Area (only for color) |
|
Image processing |
GAMMA / Contrast / Black Level / Noise Reduction / 3D Noise Reduction/ Sharpness / RGB Gain/ Saturation (RGB Gain and Saturation only for color camera) |
|
Image data format |
8bit /10bit RAW |
|
Photo Format |
JPEG / BMP / PNG / RAW |
|
Built-in buffer |
32K bit |
|
Product ID |
User Defined |
|
Model No |
GM503M-H |
|
Pixels |
5.0MP（Mono） |
|
Sensor |
MT9P031 |
|
Sensor Size |
1/2.5" |
|
Maximum Resolution |
2592(H) x 1944(V) |
|
Pixel Size |
2.2μm x 2.2μm |
|
Resolution/Frame Rate |
14FPS |
|
BIN |
2 x 2 / 4 x 4 |
|
ROI |
Any Area（ROI） |
|
Shutter |
Rolling Shutter |
|
Exposure Time |
0.036ms ～ 3000ms |
|
Sensitivity |
1.4V/Lux-sec |
|
Spectral Range |
380nm ～ 1100nm |
|
SNR |
38.1dB |
|
Dynamic Range |
70.1dB |
|
Oprating Mode |
Continuous Output / Software Trigger |
|
Built-in buffer |
32MB |
|
Exposure |
Manual / Auto / Area |
|
White Balance |
Manual / One-Time / Auto / Area (only for color camera) |
|
Image processing |
Work Speed / Image Size/ Brightness/ Exposure/ RGB Gain/GAMMA /Contrast/Saturation/Black Balance/ Sharpness /2D、3D Noise Reduction/ ( Saturation only for color camera) |
|
Image data format |
8bit / 12bit RAW |
|
Built-in buffer |
32K bit |
|
Product ID |
User Defined |
|
Data Interface |
GIGE VISION（RJ45 Connectors） |
|
Transmission Distance |
100 Meters |
|
Software Interface |
GIGE Vision V1.2 / GENICAM / DirectShow / TWAIN |
|
Operating System |
Windows XP(32 bit) / Windows7(32 bit/64 bit) / Windows8(32 bit/64 bit) / Windows8.1(32 bit/64 bit) / Windows10(64 bit) |
|
Lens Mount |
C / CS Mount |
|
Dimension (mm) |
44mm x 44mm x 42mm |
|
Weight |
Approx. 150g |
|
Rated Voltage (V) |
9～24V（Standard 12V Power Supply） |
|
Rated power (W) |
< 2.5W |
|
Working Temperature |
0～50℃ |
|
Working Humidity |
10%～90%RH（No condensation） |
|
Safety Standards |
CE ROHS |
|
Model No |
GM503-H |
|
Pixels |
5.0MP（Color） |
|
Sensor |
MT9P006 |
|
Sensor Size |
1/2.5" |
|
Maximum Resolution |
2592(H) x 1944(V) |
|
Pixel Size |
2.2μm x 2.2μm |
|
Resolution/Frame Rate |
14FPS |
|
BIN |
2 x 2 / 4 x 4 |
|
ROI |
Any Area（ROI） |
|
Shutter |
Rolling Shutter |
|
Exposure Time |
0.036ms ～ 3000ms |
|
Sensitivity |
1..76V/Lux-sec |
|
Spectral Range |
380nm ～ 650nm （with infrared filter） |
|
SNR |
38.5dB |
|
Dynamic Range |
67.7dB |
|
Oprating Mode |
Continuous Output / Software Trigger |
|
Built-in buffer |
32MB |
|
Exposure |
Manual / Auto / Area |
|
White Balance |
Manual / One-Time / Auto / Area (only for color camera) |
|
Image processing |
Work Speed / Image Size/ Brightness/ Exposure/ RGB Gain/GAMMA /Contrast/Saturation/Black Balance/ Sharpness /2D、3D Noise Reduction/ ( Saturation only for color camera) |
|
Image data format |
8bit / 12bit RAW |
|
Built-in buffer |
32K bit |
|
Product ID |
User Defined |
|
Data Interface |
GIGE VISION（RJ45 Connectors） |
|
Transmission Distance |
100 Meters |
|
Software Interface |
GIGE Vision V1.2 / GENICAM / DirectShow / TWAIN |
|
Operating System |
Windows XP(32 bit) / Windows7(32 bit/64 bit) / Windows8(32 bit/64 bit) / Windows8.1(32 bit/64 bit) / Windows10(64 bit) |
|
Lens Mount |
C / CS Mount |
|
Dimension (mm) |
44mm x 44mm x 42mm |
|
Weight |
Approx. 150g |
|
Rated Voltage (V) |
9～24V（Standard 12V Power Supply） |
|
Rated power (W) |
< 2.5W |
|
Working Temperature |
0～50℃ |
|
Working Humidity |
10%～90%RH（No condensation） |
|
Safety Standards |
CE ROHS |
|
Model No |
GM1003-H |
|
Pixels |
10MP (Mono) |
|
Sensor |
MT9J003 |
|
Sensor Size |
1/2.3" |
|
Maximum Resolution |
3664(H) x 2748(V) |
|
Pixel Size |
1.67μm x 1.67μm |
|
Resolution/Frame Rate |
8FPS |
|
BIN |
_ |
|
ROI |
Any Area（ROI） |
|
Shutter |
Rolling Shutter |
|
Exposure Time |
0.061ms ～ 3000ms |
|
Sensitivity |
0.31V/Lux-sec |
|
Spectral Range |
380nm ～ 650nm （with infrared filter） |
|
SNR |
34dB |
|
Dynamic Range |
65.2dB |
|
Oprating Mode |
Continuous Output / Software Trigger |
|
Built-in buffer |
32MB |
|
Exposure |
Manual / Auto / Area |
|
White Balance |
Manual / One-Time / Auto / Area (only for color camera) |
|
Image processing |
Work Speed / Image Size/ Brightness/ Exposure/ RGB Gain/GAMMA /Contrast/Saturation/Black Balance/ Sharpness /2D、3D Noise Reduction/ ( Saturation only for color camera) |
|
Image data format |
8bit /10bit/12bit RAW |
|
Built-in buffer |
32K bit |
|
Product ID |
User Defined |
|
Data Interface |
GIGE VISION（RJ45 Connectors） |
|
Transmission Distance |
100 Meters |
|
Software Interface |
GIGE Vision V1.2 / GENICAM / DirectShow / TWAIN |
|
Operating System |
Windows XP(32 bit) / Windows7(32 bit/64 bit) / Windows8(32 bit/64 bit) / Windows8.1(32 bit/64 bit) / Windows10(64 bit) |
|
Lens Mount |
C / CS Mount |
|
Dimension (mm) |
44mm x 44mm x 42mm |
|
Weight |
Approx. 150g |
|
Rated Voltage (V) |
9～24V（Standard 12V Power Supply） |
|
Rated power (W) |
< 2.5W |
|
Working Temperature |
0～50℃ |
|
Working Humidity |
10%～90%RH（No condensation） |
|
Safety Standards |
CE ROHS |
