Specification |
Model |
|||||
|
MIC-179 |
MIC-179A |
MIC-179B |
MIC-179C |
MIC-179T |
||
|
Viewing Head |
Monocular head,inclined at 45 °， 360° rotatable |
● |
● |
● |
|
|
|
Compensation free binocular head,inclined at30°(48mm- 75mm) |
|
|
|
● |
|
|
|
Compensation free binocular head,inclined at30°(48mm- 75mm) |
|
|
|
|
● |
|
|
Eyepiece |
WF10×/18mm |
● |
● |
● |
● |
● |
|
Objective |
Achromatic objective:4×、10×、40×(s) |
● |
● |
|
|
|
|
Achromatic objective:4×、10×、40×(s)、100×(s)Oil |
|
|
● |
● |
● |
|
|
Stage |
Plain stage with slide clips Stage Size：120mmX125mm |
● |
● |
|
|
|
|
Double layer mechanical stage Stage Size：135mmX135mm Moving Range：70mm×50mm |
|
|
● |
● |
● |
|
|
Condenser |
0.65 Condenser with disc diaphragm |
● |
|
|
|
|
|
0.65 Condenser with iris diaphragm |
|
● |
|
|
|
|
|
N.A.1.25 Abbe condenser with iris diaphragm and filter holder |
|
|
● |
● |
● |
|
|
Focusing |
Separated coarse & fine focusing adjustment |
● |
● |
● |
● |
● |
|
Light Source |
LED,brightness adjustable |
● |
● |
● |
● |
● |
|
Optional Accessory |
Eyepiece：WF16×、WF20×、P16× Achromatic objective：20×（s）、60×(s) Reflector、Dual viewing head |
|||||
|
Specification |
Model |
|||
|
MIC-179H |
MIC-179D |
MIC-179E |
||
|
ViewingHead |
Monocular head,inclined at 45 °， 360° rotatable |
● |
|
|
|
Compensation free binocular head,inclined at30°(48mm- 75mm) |
|
● |
|
|
|
Compensation free binocular head,inclined at30°(48mm- 75mm) |
|
|
● |
|
|
Eyepiece |
WF10×/18mm |
● |
● |
● |
|
Objective |
Achromatic objective:4×、10×、40×(s)、100×(s)Oil |
● |
● |
● |
|
Stage |
Double layer mechanical stage |
|
|
|
|
Stage size：135mm×135mm |
● |
● |
● |
|
|
Moving Range：70mm×50mm |
|
|
|
|
|
Condenser |
N.A.1.25 Abbe condenser with iris diaphragm & filter holder |
● |
● |
● |
|
Focusing |
Coaxial coarse & fine focusing adjustment,fine focusing scale value 0.002mm focusing range30mm |
● |
● |
● |
|
Light Source |
LED,Brightness adjustable |
● |
● |
● |
|
Optional Accessory |
Eyepiece：WF16×、WF20×、P16× Objective：20×（s）、60×(s) Reflector、Dual viewing head |
|||
