Model |
MIC-Y1000 |
|
Camera Sensor |
1/2.3”color 10MP CMOS chip |
|
Camera Sensor |
3840*2160 |
|
Pixels Size |
1.67μmm x1.67μm |
|
Frame rate |
2fps @3840*2160 |
|
30 fps @640*480 |
|
|
Shutter |
Electronic shutter |
|
SNR |
65.2 dB |
|
Scan model |
progressive |
|
Working temperature |
0°C~50°C |
|
Sensitivity |
0.31V/lux-sec@550nm |
|
Spectral response |
400nm～1000nm |
|
Digital interface |
USB2.0 (480 Mbit / sec) |
|
Power supply |
No out power supply |
|
Current |
≈200 mA |
|
White balance |
Auto, manual |
|
Automatic exposure control |
Automatic exposure |
|
Software function |
Photography, video, measurement and etc. |
|
Applicatioin |
Micro image, ordinary image capture, microspur image and etc. |
|
Model |
MIC-Y500 |
|
Camera Sensor |
1/2.5”color 5MP CMOS chip |
|
Camera Sensor |
2592*1944 |
|
Pixels Size |
2.2μmm x 2.2μm |
|
Frame rate |
15fps @ 2592*1944 |
|
30 fps @1920*1080 |
|
|
Shutter |
Electronic shutter |
|
SNR |
42.3 dB |
|
Scan model |
progressive |
|
Working temperature |
0°C~50°C |
|
Sensitivity |
1.4V/lux-sec@550nm |
|
Spectral response |
400nm～1000nm |
|
Digital interface |
USB2.0 (480 Mbit / sec) |
|
Power supply |
No out power supply |
|
Current |
≈200 mA |
|
White balance |
Auto, manual |
|
Automatic exposure control |
Automatic exposure |
|
Software function |
Photography, video, measurement and etc. |
|
Applicatioin |
Micro image, ordinary image capture, microspur image and etc. |
|
Model |
MIC-Y300 |
|
Camera Sensor |
1/2.0”color 3MP CMOS chip |
|
Camera Sensor |
2048*1536 |
|
Pixels Size |
2.2μmm x 2.2μm |
|
Frame rate |
15fps @ 2592*1944 |
|
30 fps @1920*1080 |
|
|
Shutter |
Electronic shutter |
|
SNR |
42.3 dB |
|
Scan model |
progressive |
|
Working temperature |
0°C~50°C |
|
Sensitivity |
1.8V/lux-sec@550nm |
|
Spectral response |
400nm～1000nm |
|
Digital interface |
USB2.0 (480 Mbit / sec) |
|
Power supply |
No out power supply |
|
Current |
≈200 mA |
|
White balance |
Auto, manual |
|
Automatic exposure control |
Automatic exposure |
|
Software function |
Photography, video, measurement and etc. Free drive support Windows2000\XP2\Vista\Win7 |
|
Applicatioin |
Micro image, ordinary image capture, microspur image and etc. |
|
Model |
MIC-Y200 |
|
Camera Sensor |
1/3.0”color 2MP CMOS chip |
|
Camera Sensor |
1920*1080 |
|
Pixels Size |
2.2μmm x 2.2μm |
|
Frame rate |
30fps @1920*1080 |
|
30 fps @ 800 x 600 |
|
|
Shutter |
Electronic shutter |
|
SNR |
39 dB |
|
Scan model |
progressive |
|
Working temperature |
-10°C~50°C |
|
Sensitivity |
1.8V/lux-sec@550nm |
|
Spectral response |
400nm～1000nm |
|
Digital interface |
USB2.0 (480 Mbit / sec) |
|
Power supply |
No out power supply |
|
Current |
≈200 mA |
|
White balance |
Auto, manual |
|
Automatic exposure control |
Automatic exposure |
|
Software function |
Photography, video, measurement and etc. Free drive support Windows2000\XP2\Vista\Win7 |
|
Applicatioin |
Micro image, ordinary image capture, microspur image and etc. |
|
Model |
MIC-Y201 |
|
Camera Sensor |
1/3.2”color 2MP CMOS chip |
|
Camera Sensor |
1600 x 1200 |
|
Pixels Size |
2.8μmm x 2.8μm |
|
Frame rate |
15fps @ 1600 x 1200 |
|
30 fps @640 x 480 |
|
|
Shutter |
Electronic shutter |
|
SNR |
42.3 dB |
|
Scan model |
progressive |
|
Working temperature |
0°C~50°C |
|
Sensitivity |
1.8V/lux-sec@550nm |
|
Spectral response |
400nm～1000nm |
|
Digital interface |
USB2.0 (480 Mbit / sec) |
|
Power supply |
No out power supply |
|
Current |
≈200 mA |
|
White balance |
Auto, manual |
|
Automatic exposure control |
Automatic exposure |
|
Software function |
Photography, video, measurement and etc. Free drive support Windows2000\XP2\Vista\Win7 |
|
Applicatioin |
Micro image, ordinary image capture, microspur image and etc. |
|
Model |
MIC-Y202 |
|
Camera Sensor |
1/2”color 2MP CMOS chip |
|
Camera Sensor |
1280 x 1024 |
|
Pixels Size |
5.2μmm x 5.2μm |
|
Frame rate |
10fps @ 1280 x 1024 |
|
30 fps @640 x 480 |
|
|
Shutter |
Electronic shutter |
|
SNR |
62 dB |
|
Scan model |
progressive |
|
Working temperature |
0°C~50°C |
|
Sensitivity |
1.8V/lux-sec@550nm |
|
Spectral response |
400nm～1000nm |
|
Digital interface |
USB2.0 (480 Mbit / sec) |
|
Power supply |
No out power supply |
|
Current |
≈200 mA |
|
White balance |
Auto, manual |
|
Automatic exposure control |
Automatic exposure |
|
Software function |
Photography, video, measurement and etc. Free drive support Windows2000\XP2\Vista\Win7 |
|
Applicatioin |
Micro image, ordinary image capture, microspur image and etc. |
