Item

Name

Order No.

      MIC-M1

Main body (finite optical system)

Mechanical tube length:160mm

MIC-M1

●

Head

Monocular head

4J.6

○

Sliding Binocular head

12X.4

●

Integrated2Mpixel sliding binocular head

12X.4.2M

○

Integrated3Mpixel sliding binocular head

12X.4.3M

○

Trinocular head

12X.4T

○

Focus

Coaxial coarse and fine adjustment, fine division0.002mm, moving range8mm

FT002

●

Stage

Mechanical stage 180x155mm, moving range: 40x30mm

4J.5

●

Mechanical Stage, 180mmx155mm; movement range: 80mmx50mm; with low-positioned X/Y coaxial control knob.

ZT5B

○

Stage clip

STJ001

●

Stage: teardrop, round hole

STD003

●

Stage plate (ø10)

4J.0-1

○

Stage plate (ø15)

4J.0-4

○

Stage plate (ø20)

12X.3-5

○

Eyepiece

Huyenian ocular WF5X-20mm

EH5

○○

Plan eyepiece WF10X-18mm

EP10a

●○

Plan eyepiece WF12.5X-14mm

EP12.5

●○

Plan eyepiece WF16X-11mm

EP16

○○

Plan reticle eyepiece WF10X-14mm

EPr10b

○○

Plan eyepiece WF10X-18mm(pointer)

EP10ap

○○

Nosepiece

Triple nosepiece

NS3

●

Quadruple nosepiece

NS4

○

Objective

Plan achromatic objective (2.5/0.07)

B-OPr2.5

○

Achromatic objective (4/0.10)

B-OAr4

  ○

Plan achromatic objective (4/0.10)

B-OPr4

○

Achromatic objective (10/0.25)

M-OAr10

●

Plan achromatic objective (40/0.65)

M-OPr40a

●

Plan achromatic objective (50/0.75)

M-OPr50a

○

Achromatic objective (100/1.25 oil)

M-OAor100

●

Plan achromatic objective (10/0.25)

M-OPr10

○

Plan achromatic objective (40/0.65)

M-OPr40

○

S-plan achromatic objective (100/1.25 oil)

M-OSpor100

○

 Filter

Color filter ø32(green, yellow, blue, gray)

●

Illumination

HALOGEN LAMP 12V/20W

Center and brightness adjustable

LYQ6-15D

●

Stage micrometer (division0.01mm)

○

SC03

Sample holder

SC03

         ○
