This serials microscope is specially developed for various applied scopes .It is widely used, from daily work to scientific research, in biology, histology, pathology, medicament chemistry research and clinical examination. Because of higher capability with lower price and humanized configuration design. It becomes the first choices of individual, colleges & schools, hospitals and scientific research organization.
Features:
1.Wide-field Eyepiece high light illumination and superior optical parts make the image clear ,sharp and bright.
2.Backward nosepiece with superior objectives makes the best viewing effect and more space for the operator.
3.Wide mechanical stage with 2-Microslide specimen clamp provides more convenience for the observer.
4.High precision focusing adjustment system and humanized configuration design provide operator more comfortable.
|
Specification |
XSZ-N4 |
XSZ-N4T |
|
|
Viewing head |
Compensation Free Binocular Head 30° |
● |
|
|
Compensation Free Trinocular Head 30° |
|
● |
|
|
Interpupillary Distance55mm-75mm |
● |
● |
|
|
Eyepiece |
WF10 × |
● |
● |
|
Objective |
Achromatic objectives:4X,10X,40X(S),100X(S) Oil |
● |
● |
|
Stage |
Double layers mechanical stage |
● |
● |
|
Stage size: 140mmx140mm |
|||
|
Moving range:75mm×50mm |
|||
|
Condenser |
Swing type N.A.1.25Abbe condenser with iris diaphragm & filter |
● |
● |
|
Focusing |
Coaxial coarse & fine focusing adjustment with rack and pinion mechanism fine focusing scale Value0.002mm |
● |
● |
|
Collector |
High brightness Kohler illumination |
● |
● |
|
Light source |
Halogen bulb 6V/20W AC 85-230V |
● |
● |
|
Adjustable brightness |
|||
|
Optional Accessory |
Eyepieces: WF16x,WF20x,P16x |
||
|
1.3Mega pixel, CMOS electronic eyepiece |
|||
|
Plan-Objectives: 4X,10X,20X(S),40X(S),60X(S),100X(S)Oil |
|||
|
Semi-plan objectives: 4X,10X,20X(S),40X(S),60X(S),100X(S)Oil |
|||
|
Infinity objectives: 4X,10X,20X(S),40X(S),60X(S),100X(S)Oil |
|||
|
Photo and CCD attachment |
|||
