XSZ-N1 with high efficiency, flexibility and stability are the characters of this series microscope. It is specially developed for various applied scopes. It is widely used, from daily work to scientific research, in Laboratory, Hospitals and Colleges. Because of higher capability with lower price and humanized configuration design, It also becomes the first choice of individual, Schools, and Scientific research organization.
Features:
|
Specification |
XSZ-N1 |
XSZ-N1T |
|
|
Viewing head |
Compensation Free Binocular Head. Inclined at 3 0 ° (55mm-75mm) |
● |
|
|
Compensation Free Trinocular Head. Inclined at 3 0 ° (55mm-75mm) |
|
● |
|
|
Eyepiece |
WF10 × |
● |
● |
|
Objective |
Achromatic objective: 4 × ,10 × ,40 × (S),100 × (S)Oil |
● |
● |
|
Stage |
Double layers mechanical stage |
● |
● |
|
Stage size:180mm×150mm |
|||
|
Moving range:75mm×50mm |
|||
|
Condenser |
N.A1.25 Abbe condenser with iris diaphragm & filter |
● |
● |
|
Focusing |
Coaxial coarse & fine focusing adjustment with rack and pinion mechanism Fine focusing scale Value0.002mm |
● |
● |
|
Collector |
High brightness Kohler illumination |
● |
● |
|
Light source |
Halogen tungsten bulb 12V/20W.AC 85V-230V |
● |
● |
|
Adjustable brightness |
|||
|
Optional Accessory |
Eyepiece：WF16×、WF20×、P16× and 1.3 Mega pixels CMOS electronic eyepiece |
||
|
Plan objective：4×、10×、20×(S)、40×(s)、60×(s)、100×(s) |
|||
|
Semi-plan Objective:4×、10×、20×(S)、40×(s)、60×(s)、100×(s) |
|||
|
Infinity Objective:4×、10×、20×、40×(s)、60×(s)、100×(s)oil |
|||
|
Phase Contrast Attachment |
|||
|
Photo and CCD attchment |
|||
