Parts

Specification

47V

47V

7VU

48U

130U

130U

200U

Optical Magnification

40X-1600X

●

●

●

●

●

●

●

Eyepiece

Wide Field WF10x/18mm

●

●

●

Wide Field WF16x/15mm

●

●

●

Wide Field WF10x/20mm, diopter adjustable

●

●

●

●

Wide Field WF16x/15mm, diopter adjustable

●

●

●

●

Digital Viewing Head

Digital monocular head, 45°inclined, built-in CCD/CMOS system

●

●

●

Digital binocular head, 30°inclined, built-in CCD/CMOS system
interpupillary distance 55-75mm

●

●

●

●

Nosepiece

4 Holes revolver, inward

●

●

●

●

●

●

●

195N
Achromatic Objective

4X

●

●

●

●

●

●

●

10X

●

●

●

●

●

●

●

40X（Spring）

●

●

●

●

●

●

●

100X（Spring, oil）

●

●

●

●

●

●

●

Plan Achromatic Objective

PL4X

PL10X

PL40X（Spring）

PL100X（Spring, oil）

Focusing System

Coaxial coarse & fine focusing knob, coarse focusing moving range22mm, fine focusing graduation0.002mm

●

●

●

●

●

●

●

Stage

Double layer mechanical stage, size 140x132mm, moving range 50x30mm

●

●

●

●

●

●

●

Double layer mechanical stage, size 140x140mm, moving range 70x50mm

Condenser

Abbe condenser N.A. 1.25, with iris diaphragm, height adjustable

●

●

●

●

●

●

●

Illumination

Critical illuminator

●

●

●

●

●

●

●

Lamp

Halogen lamp 12V/20W, brightness adjustable

●

●

●

●

●

●

●

Power

Switch power, wide power range 100V-250V

●

●

●

●

●

●

●

Voltage Plug

220V/50Hz，Chinese standard

●

●

●

●

●

●

●

According to customer's requirement

Filter

White, blue, yellow, 1 pc for each color

●

●

●

●

●

●

●

Prepared Slide

Plant prepared slide 1 pc

●

●

●

●

●

●

●

Micrometer

Micrometer0.01mm

●

●

●

●

●

●

●

Microscope
Instruction
Manual

Instruction manual (English version)

●

●

●

●

●

●

●

Packing

Aluminam case

●

●

●

●

●

●

●

CCD/CMOS System　

CCD Camera

Analog 370K pixels, 420 TV lines

Analog 470K pixels, 480 TV lines

●

●

●

CMOS Camera

Digital 480K pixels, resolution 800x600

●

Digital1.3Mpixels, resolution 1280x1024

●

●

Digital2.0Mpixels, resolution 1600x1200

●

Digital3.1Mpixels, resolution 2048x1536

Video Capture Card

AV-USB capture, resolution 720x576

●

Signal Output

Analog Video

●

●

●

Digital USB1.1

●

Digital USB2.0

●

●

●

●

Signal Cable

Digital USB2.0

●

●

●

Digital USB cable

●

●

●

●

●

Micro Image Analysis Software

Software

PHMIAS2008 Ver2.2

●

●

●

●

●

Software Manual

Software instruction manual (Chinese Version)

●

●

●

●

●

Optional Accessories

Optional Accessories

CCD with white balance button, CCD with power switch
