XSF-4 series microscope can be applied in
the field of higher education, medical and sanitation, laboratory scientific
research institute, for clinical experiment, scientific analysis and teaching
research work, on biology, pathology, bacteriology XSF-4 series biological
microscope can be easily attached with full range accessories, including photo,
CCD camera, digital camera, dark field, phase contrast, polarizing and etc. It
is the ideal tool to be used in micro biology research work.
◆Viewing Head: Compensation binocular head, 30° inclined, 360°
rotatable, interpupillary distance 55-75mm
◆Eyepiece: Wide field WF10x/ф20mm, diopter adjustable.
◆Objective: 195N achromatic 4x, 10x, 40x(Spring), 100x(Spring, Oil)
◆Nosepiece: 4 Holes revolving nosepiece, inward, steel ball bearing
position system for convenient operation
◆Stage: Double layer mechanical stage, double specimen clip Size 160x142mm, moving range 76x52mm
◆Focusing system: Coaxial coarse & fine focusing knob, triangle
steel pole track make height adjustment more smooth
◆With tension adjustment and rack stop system
◆Abbe Condenser: N.A.=1.25, iris diaphragm, center of condenser
adjustable.,
◆Illumination: Kolher illumination, halogen lamp 12V/20W, brightness
adjustable, can meet different illumination requirement
◆Power: Switch power, wide range voltage AC96-246V
◆Software: Micro Image Analysis Software, powerful function with easy
operation
|
Parts |
Specification |
47V |
47VU |
48U |
413U |
420U |
431U |
|
Optical Magnification |
40X-1600X |
● |
● |
● |
● |
● |
● |
|
Eyepiece |
Wide Field WF10x/20mm, diopter adjustable |
● |
● |
● |
● |
● |
● |
|
Wide Field WF16x/15mm, diopter adjustable |
● |
● |
● |
● |
● |
● |
|
|
Digital Viewing Head |
Digital binocular head, 30°inclined, built-in CCD/CMOS system interpupillary distance 55-75mm |
● |
● |
● |
● |
● |
● |
|
Nosepiece |
4 Holes revolver, inward |
● |
● |
● |
● |
● |
● |
|
195N Achromatic Objective |
4X |
● |
● |
● |
● |
|
|
|
10X |
● |
● |
● |
● |
|
|
|
|
40X（Spring） |
● |
● |
● |
● |
|
|
|
|
100X（Spring, oil） |
● |
● |
● |
● |
|
|
|
|
Plan Achromatic Objective |
PL4X |
|
|
|
|
● |
● |
|
PL10X |
|
|
|
|
● |
● |
|
|
PL40X（Spring） |
|
|
|
|
● |
● |
|
|
PL100X（Spring, oil） |
|
|
|
|
● |
● |
|
|
Focusing System |
Coaxial coarse & fine focusing knob, coarse range moving range22mm, fine focusing graduation0.002mm |
● |
● |
● |
● |
● |
● |
|
Stage |
140mm×132mm，76mm×52mm |
● |
● |
● |
● |
● |
● |
|
Condenser |
Abbe condenser N.A. 1.25, with iris diaphragm, height adjustable |
● |
● |
● |
● |
● |
● |
|
Illumination |
Kohler illumination |
● |
● |
● |
● |
● |
● |
|
Lamp |
Halogen lamp 12V/20W, brightness adjustable |
● |
● |
● |
● |
● |
● |
|
LED 3W, not rechargable, brightness adjustable |
|
|
|
|
|
|
|
|
Power |
Switch power, wide power range 100V-250V |
|
|
|
|
|
|
|
Electrical transformer |
● |
● |
● |
● |
● |
● |
|
|
Voltage Plug |
220V/50Hz |
● |
● |
● |
● |
● |
● |
|
Filter |
White, blue, yellow, 1 pc for each color |
● |
● |
● |
● |
● |
● |
|
Prepared Slide |
Plant prepared slide 1 pc |
● |
● |
● |
● |
● |
● |
|
Micrometer |
Micrometer0.01mm |
● |
● |
● |
● |
● |
● |
|
Microscope Instruction Manual |
Instruction manual (English version) |
● |
● |
● |
● |
● |
● |
|
Packing |
Aluminam case |
● |
● |
● |
● |
● |
● |
|
CCD/CMOS System |
|||||||
|
CCD Camera |
Analog 370K pixels, 420 TV lines |
|
|
|
|
|
|
|
Analog 470K pixels, 480 TV lines |
● |
● |
|
|
|
|
|
|
CMOS Camera |
Digital 480K pixels, resolution 800x600 |
|
|
● |
|
|
|
|
Digital1.3Mpixels, resolution 1280x1024 |
|
|
|
● |
|
|
|
|
Digital2.0Mpixels, resolution 1600x1200 |
|
|
|
|
● |
|
|
|
Digital3.1Mpixels, resolution 2048x1536 |
|
|
|
|
|
● |
|
|
Video Capture Card |
AV-USB capture, resolution 720x576 |
|
● |
|
|
|
|
|
Signal Output |
Analog Video |
● |
● |
|
|
|
|
|
Digital USB1.1 |
|
|
● |
|
|
|
|
|
Digital USB2.0 |
|
● |
|
● |
● |
● |
|
|
Signal Cable |
Digital USB2.0 |
● |
● |
|
|
|
|
|
Digital USB cable |
|
● |
● |
● |
● |
● |
|
|
Micro Image Analysis Software |
|||||||
|
Software |
PHMIAS2008 Ver2.2 |
|
● |
● |
● |
● |
● |
|
Software Manual |
Software instruction manual (Chinese Version) |
|
● |
● |
● |
● |
● |
|
Optional Accessories |
|||||||
|
Optional Accessories |
CCD with white balance button, CCD with power switch |
|
|
|
|
|
|
Note: “●” in the table is standard attachment. “○” is optional accessories.
Design change: To keep pace with
technological advances, we have reserved the right to
make design modification
and changes without notice.
