Head

Available with Monocular, Binocular, Dual View or Trinocular heads. Binocular and Trinocular heads feature Seidentopf optical design with 52 to75 mminterpupilary distance adjustment. All rotate rotates 360° and lock in-place with a thumbscrew

Coated Optics

All optics feature the following coatings: Anti-Glare, Color Correction, Anti-Fungal

Eyepiece

Standard with 10X High-Eyepoint widefield oculars. Standard widefield oculars are also available. FN =18 mm, optional20 mmavailable

Objectives

DIN Standard 4X, 10X, 40XP and 100XR (Oil) objectives. 40X and 100X objectives are "R", or retractable. Nosepiece: 4 hole standard. Options are: Achromat, Semi-Plan, or Plan Achromats. Simple Phase Contrast is available in 10X, 40X and 100X Semi-Plan. 4X = NA 0.10, 10X = NA 0.25, 40X = NA 0.65, 100X = NA 1.25. Focal Length:160 mm

Magnification

With 10X eyepieces, standard magnification is 40X, 100X, 400X and 1,000X

Stand

Sturdy cast metal frame with unique polymer accent panel, designed to provide stability while dissipating bulb heat

Condenser

Features a focusable NA 1.25 Abbe condenser with port for optional Simple Phase Contrast Annulus insertion. Focusable for concentrated or diffuse lighting with rack and pinion movement

Focusing

Smooth, extra-large graduated coaxial coarse and fine focus controls with tension adjustment to eliminate stage drift. Adjustable to your personal preferences

Stage

Built-in graduated mechanical stage with low-position coaxial X-Y controls. Ball bearing movement allows for smooth, precise adjustments. Stage size:142 mmx132 mm. Range of X-Y stage movement:55 mmx75 mm. Spring loaded slide holder

Illumination

Features a 6V/20W Halogen light source for consistent bright white light. Variable intensity rheostat wheel is located on the left side of the base

Iris Diaphragm

Features adjustable Iris with metal leaf overlay design

Electrical

110V-60 Hz to 240V-50 Hz, universal power supply. The fuse rating is 250V1.5A. UL & CSA approved electrical parts

Warranty

5-year limited warranty, excludes bulb and fuses

Other

Plastic dust cover included
