Item

Order NO.     Name

BA3000i

EPh10b

10×High Point Wide Field Eyepiece/ WF10×-22

●●

B-OPi4a

4×Infinity Plan Achromatic Objective/ PL 4×/-

●

B-OPi10a

10×Infinity Plan Achromatic Objective/ PL 10×/0.25

●

B-OPi20a

20×Infinity Plan Achromatic Objective/ PL(s) 20×/0.40

●

B-OPi40a

40×Infinity Plan Achromatic Objective/ PL(s) 40×/0.66

●

B-OPoi100a

100×Infinity Plan Achromatic Objective (Oil)

●

A15

Main Body/ Five Holes Transducer (two filling-in bits)

●

TTR07

Rotating Trinocular/ Binocular Adjustment (eyepiece tube sizeØ30)

●

S35

Stages/Fast Change/Size 180×142/Moving Range 80×55

●

CA11

Trays/Fast Change

●

C28

All light Achromatic Condenser/ N.A.0.92 /0.13

●

KI 01

Kola Illumination System/field irisØ2-Ø35

●

LH 09

Lamp House/12V 50W，Fuse3A(Ø5x20）

●

11X.1.5-37

Green Filter/Ø38

●

11X.1.5-38

Blue Filter/Ø38

●

11X.1.5-39

Yellow Filter/Ø38

●

11X.1.5-40

Grey Filter/Ø38

●

Order number

Name

EPhg10

Wide Field Eyepiece with Pointer (High Point) /WF 10×-22

EPh16b

High Point Wide Field Eyepiece /WF16×-16

B-OAi4b

Achromatic Objective 4×/-

B-OAi10b

Achromatic Objective 10×/0.25

B-OAi40b

Achromatic objective  40×/0.66（s）

B-OAio100b

Achromatic Objective 100×/1.25 Oil（s）

B-OPip10a

Infinity Plan Positive Phase Objective /PL ph+ 10×/0.25

B-OPip20a

Infinity Plan Positive Phase Objective /PL(s) ph+ 20×/0.40

B-OPip40a

Infinity Plan Positive Phase Objective /PL(s) ph+ 40×/0.66

B-OPoip100a

Infinity Plan Positive Phase Objective /PL(s) ph+ 100×/1.25 Oil

B-OPin10

Infinity Plan Negative Phase Objective /PL ph- 10×/0.25

B-OPin20

Infinity Plan Negative Phase Objective /PL(s) ph- 20×/0.40

B-OPin40

Infinity Plan Negative Phase Objective /PL(s) ph- 40×/0.66

B-OPoin100

Infinity Plan Negative Phase Objective/PL(s) ph-100×/1.25 Oil

ECia

Centering Telescope/20x/Ø30

C29

Phase Condenser /N.A.1.25

C30

Dark Field Condenser/ N.A. 0.83-0.91

PO05

Polarizer

PA04

Analyzer

EPhr10

High Point Wide Field Reticule Eyepiece 10×/Grid0.1mm

EPHn2.5a

Photo Eyepiece 2.5×/ Image Size Ø42

EPHn4a

Photo Eyepiece 4×/ Image Size Ø42

MP06

135 Photo Device/ Match with 20 and 21

TV09b

Photo Device (With 0.35x System)/ 1/3″CCD

0.01mm Micrometer/ Grid0.01mm

TV09c+DV03

Digital Photo Device /OLYMPUSDigital Camera C5000 Serials

II 09

Reflective-transmitted Device/6V 20W

FD 06

Fluorescent Vertical Illumination /UV、V 、B、G Four Kinds

B-OFi10

Infinity Plan Fluorescent Objective 10×/ FPL 10X/0.30

B-OFi25

Infinity Plan Fluorescent Objective 25×/ FPL 25X/0.65

B-OFi40

Infinity Plan Fluorescent Objective 40×/ FPL 40X/0.85

B-OFoi100

Infinity Plan Fluorescent Objective (glycerol) 100×/ FPL 100X/1.25 GLYC

LH08

DC Hg Lamp House 100W

PS-2

DC Hg Lamp House 100W

Glycerol
