VM-6380 3 axis VIBRATION METER
Used for measuring periodic motion, to check the imbalance and deflecting of moving machinery. Specifically designed for present measuring various mechanical vibration. So as to provide the data for the quality control, run time and equipment upkeep.
Features:
* 3 same parameters in one display for 3 dimensional measurement or 1 dimensional measurement specified, showing 3 different parameters of velocity, acceleration and displacement in 1 display.
* In accordance with ISO 2954, used for
periodic measurements, to detect out-of-balance, misalignment and other
mechanical faults in rotating machines.
* Specially designed for easy on site vibration measurement of all rotating
machinery for quality control, commissioning, and predictive maintenance
purposes.
* Individual high quality accelerometer for
accurate and repeatable measurements.
* Wide frequency range (10Hz~10kHz) in acceleration mode.
* Optional headphones for use as electronic stethoscope.
* Bearing condition monitoring function.
* Use “USB data output” and “RS-232 data output” to connect with PC.
|
Sensor |
3-Axis Piezoelectric Accelerometer |
|
Measuring Range |
Acceleration: 0.1~400 m/s² 0.3~1312 ft/s² 0.0~40 g Equivalent Peak |
|
Velocity: 0.01~400 mm/s 0.004~16.0 inch/s True RMS |
|
|
Displacement: 0.001~4.0 mm 0.04~160.0 mil Equivalent Peak-peak |
|
|
Frequency Range |
Acceleration: 10 Hz ~ 1k Hz 10 Hz ~ 10k Hz |
|
Velocity: 10 Hz ~ 1k Hz |
|
|
Displacement: 10 Hz ~ 1k Hz |
|
|
Accuracy |
5 % of Reading + 2 digits |
|
Metric / Imperial Conversion |
|
|
Analogue Output |
AC Output 0~2.0 V Peak Full Scale (Load Resistance: Above 10k) |
|
Max. Value Hold |
|
|
Power Off |
Manual Power Off or Auto Power Off |
|
Battery Indicator |
Low Battery Indicator |
|
Data Output |
USB, RS-232 |
|
Operating Conditions |
Temperature: 0~50 °C Humidity: <90 %RH |
|
Power Supply |
2 x 1.5V AA size (UM-3) Battery |
|
Dimensions |
130 x 76 x 32 mm |
|
Weight |
340 g (Not Including Batteries) |
Standard Accessories:
1. Main Unit
2. Magnetic Suction Seat
3. 3-Axis Piezoelectric Accelerometer
4. Probe (Cone)
5. Probe (Spherical)
6. Carrying Case
7. Manual Book
Optional Accessories:
1. Headset
2. USB, RS-232 data cable with software
