HT-6510MF memory foam hardness tester
Memory Foam Hardness Tester HT-6510MF special for memory foam hardness measurement.(memory foam is also known as slow rebound sponge, space zero pressure, space cotton, TEMPUR material, low rebound sponge material, viscous elastic, used in high velocity of aerospace, aviation, equipment, high-end consumer goods.)
Features:
* Specially for hardness testing of MEMORY FOAM.
* It meets standards of DIN 53505, ISO 868, ISO 7619, ASTMD 2240, JISK7215.
* With average calculate function.
* Peak value deposit function.
* Under-voltage alarm function.
* Use “USB data output” and “RS-232 data output” to connect with PC.
* Provide “Bluetooth ™ data output” choice.
|
Parameters Displayed |
Hardness Result, Average Value, Max. Value |
|
MeasurementRange |
0 ~ 100 HMF |
|
Measurement Deviation |
＜ 1% HMF |
|
Resolution |
0.1 HMF |
|
Spring Force |
455 gf |
|
Sensor Head Diameter |
25mm |
|
Sensor Foot Diameter |
80mm |
|
Auto Switch Off |
|
|
BatteryIndicator |
LowBatteryIndicator |
|
Operating Conditions |
Temperature: 0 ~40 ℃Humidity: 10 ~ 90 %RH |
|
Power Supply |
4 x 1.5 V AAA Size (UM-4)Battery |
|
Dimensions |
162 x 80 x 80 mm(6.4 x 3.1 x 3.1 inch) |
|
Weight |
250 g（Not Including Batteries） |
Standard Accessories
1. Main Unit
2. Carrying Case
3. Operation Manual
Optional Accessories
1. USB, RS-232Cdata cable with software
2. Bluetooth data out put with software
