DC-3000CSERIES ULTRASONIC THICKNESS GAUGE
Product Details:
Features
● The through-Coating thickness Measurement (Echo-Echo)
● Automatic probe zero calibration
● Automatic probe identify
● Limited setting and alarm
● Varies measurement modes: transmit-echo, echo-echo, scan
●Gain adjustable
● Large memory up to 5000 group readings (3020C)
● USB output to PC
Technical Specification
Specification |
DC3000C |
DC3020C |
||
Measurement mode |
Transmit –echo |
-Standard measurement: For Normal thickness measurement. -Minimum measurement: For curved surface -Differential measurement: Displays the difference from the actual thickness -measurement and a user entered reference value Average measurement : 2-9 point selectable -Limit measurement: Min. Max setting and alarm |
√ |
√ |
Echo-Echo |
The metal wall thickness is accurately and quickly measured in spite of surface coating |
√ |
√ |
|
Scan |
thickness value at 10 measurements per second while also display actual thickness (Ideal for high temp. thickness readings) |
√ |
√ |
|
Probe identify |
Auto |
√ |
√ |
|
Probe zero |
Auto at power up and continuously during the measurement |
√ |
√ |
|
Gain adjust |
Auto gain adjustment Manual gain adjustment, low, standard and high |
√ |
√ |
|
Memory |
5000 groups |
-- |
√ |
|
Output |
USB to PC |
-- |
√ |
|
Measuring Range |
0.65-400mm(0.025-15.748inch) (range depends on probe-material combination) |
√ |
√ |
|
Resolution |
0.01mm (0.001 inch) for thickness up to99.99mm 0.1mm ( 0.01 inch) for thickness above99.99mm |
√ |
√ |
|
Information Display |
Measurement reading, Probe type, Velocity, measurement mode, measurement Symbol,Battery |
√ |
√ |
|
Velocity range |
9 material velocities are stored for selection, or entre the new velocity manually (1000m/s-9999m/s) |
√ |
√ |
|
Velocity measurement |
Simply calibrate when a material’s velocity is unknown |
√ |
√ |
|
Display |
128 x 64 graphics LCD monochrome |
√ |
√ |
|
Battery Type |
2 AAA Alkaline |
√ |
√ |
|
Battery life |
Up to 50 Hours (without Backlight) |
√ |
√ |
|
Shut off |
Auto, 2Min., 5Min., or never shut off delectable |
√ |
√ |
|
Working Temperature |
-20℃-50℃ |
√ |
√ |
|
Unit |
mm/inch |
√ |
√ |
|
Dimensions |
115mm x64mmx27mm |
√ |
√ |
|
Weight |
220g |
√ |
√ |
Specification for optional transducer
Model |
Frequency |
Measuring range |
Diameter |
Temperature |
D5301 |
5.0MHz |
T-E 0.8-300mm E-E 4-25mm |
Ø10.8 |
<60℃ |
D5008 |
5.0MHz |
0.8-300mm |
Ø10.8 |
<60℃ |
D5113 |
5.0MHz |
3.0-200mm |
Ø13 |
<350℃ |
D7006 |
7.5MHz |
0.7-50mm |
Ø8.5 |
<60℃ |
D7004 |
10.0MHz |
0.65-20mm |
Ø5 |
<60℃ |
D2012 |
2.0MHz |
2.0-400.0mm |
Ø16.3 |
<60℃ |
Standard Delivery
● Main unit
● Standard 5MHz transducer D5301
● Operation manual
● Two AAA batteries
● Built-in calibration block
● Software and Cable (3020C)
● Carrying case
● Couplant
