GED-2600P engine tachometer
The hand-held engine tachometer displays rotational speed of gasoline engines in r / min unit. It is a non-contacting type tachometer which easily measures the rotational speed just by bringing the detection head close to the high-tension wires of gasoline engines. Applicable to the product departments of motor, fan, paper-product, plastics, chemical fiber, washing-machine, automobile, airplane, steamer etc.
Features:
* Non-contacting detection enables an easy and safe measurement.
* It assures an accurate measurement because the signal indicator shows how the signal is captured.
* Accurate rotational speed can be obtained in 0.1 or 1 r / min unit.
* When the battery runs out or the voltage drops, the battery signal at the lower left corner of the display panel lights up.
* The four-digit LCD is suitable for out-door measurement.
* Compact, light weight and easy-to-carry, enabling one-hand measurement.
|
Display |
5 Digits10 mmLCD |
|
Applications |
2-Cycle ( 1, 2, 3, 4 Cylinder ) |
|
4-Cycle ( 1, 2, 3, 4, 5, 6, 8 Cylinder ) |
|
|
Range |
100 ~ 9,999 r / m |
|
Detection Method |
Ignition Spark Noise Detection |
|
Accuracy |
(0.05% n + 1 d ) |
|
Resolution |
0.1 / 1 |
|
Memory |
Max / Min / Last Value |
|
Power Supply |
2 x 1.5 V AAA Size (UM-4)Battery |
|
Dimensions |
97 x 35 x 25 mm |
|
Weight |
65 g ( Including Batteries ) |
Standard Accessories:
1. Main Unit
2. Carrying Case
3. Operation Manual
