QG-4A Multifunctional Cutting Machine with fast clamping

QG-4A multifunctional cutting machine is mainly used for cutting irregular general metallographic sample materials such as round cylinder and polygon and protruding platforms, etc. This machine adopts double-shells totally closed structure and quick clamp organization. It can guarantee cutting under absolutely safe status, this machine equipped with front, back, left, and right board, the thickness of sample can be changed arbitrarily, and the speed of entering is controllable. In order to avoid the sample organization burns because of being overheated in cutting, this machine is furnished with the strong cooling system, and the sample can be transferred arbitrarily to the location while cutting, can avoid little burn of the sample surface while cutting and falling, can increase the cutting section, improve the utilization ratio of cutting emery wheel slice; it has convenient advantages in operation, maintenance; it is the extremely good apparatus for cutting irregular sample materials.

Main parameters：

Maximum Cutting Cross Section：65×65mm

Platen Speed：2800 r/min

Cutting Wheel Size：φ250×2×φ32mm

Electromotor：YS802-2，1.2KW，380V，50Hz

Total Dimension：700×520×1110mm

Net weight：170Kg
