MC-7828Ggrain moisture meter cup type
Used for fast and accurate measurement of moisture in the process of allotment, acquisition, storage, machining of packed grains, feedstuff, powder.
Features:
* Able to measure grains up to 22 species.
* The cup type measurement causes small error.
* Wide measuring range.
* Two presentations, digital display and color coded LED indication.
* Use the exclusive Micro-computer LSI circuit and crystal time base to offer high accuracy measurement. It can obtain automatically the temperature corrected moisture value.
* Use “USB data output” and “RS-232 data output” to connect with PC.
* Provide “Bluetooth ™ data output” choice.
Grain Code:
|
Code |
Grain |
Range（%） |
|
Cd01 |
Japonica Rice |
0~50 |
|
Cd02 |
Soya Beans |
0~35 |
|
Cd03 |
Wheat |
0~50 |
|
Cd04 |
Rapeseed |
0~35 |
|
Cd05 |
Corn |
0~50 |
|
Cd06 |
Barley |
0~50 |
|
Cd07 |
Indica Rice |
0~50 |
|
Cd08 |
Rice |
0~50 |
|
Cd09 |
Bean Pulp |
0~50 |
|
Cd10 |
Peanut |
0~50 |
|
Cd11 |
Rapeseed Meal |
0~50 |
|
Cd12 |
Granulated Feed |
0~50 |
|
Cd13 |
Sunflower Seed |
0~35 |
|
Cd14 |
Watermelon Seed |
0~30 |
|
Cd15 |
White Wheat |
0~50 |
|
Cd16 |
Sorghum |
0~50 |
|
Cd17 |
Black Sesame |
0~45 |
|
Cd18 |
Northeast Corn |
0~50 |
|
Cd19 |
Cottonseed |
0~50 |
|
Cd20 |
Cottonseed Meal |
0~50 |
|
Cd21 |
Coffee Beans |
0~45 |
|
Cd22 |
Cocoa Beans |
0~40 |
Moisture Meter Wishlist:
|
Wood Moisture Meter |
Tobacco Moisture Meter |
|
Paper Moisture Meter |
Cigarette Moisture Meter |
|
Seed Cotton Moisture Meter |
Feed Moisture Meter |
|
Wood Flour Moisture Meter |
Chinese Medicine Moisture Meter |
|
Paperboard Moisture Meter |
Tea-leaves Moisture Meter |
|
Grain Moisture Meter |
Foan Material Moisture Meter |
|
Waste Paper Moisture Meter |
Plastic Cement Moisture Meter |
|
Grains |
22 Species |
|
Measuring Range |
0~50 % |
|
Accuracy |
±（0.5n%+0.5） |
|
Resolution |
0.1 |
|
Display |
4 Digits,10 mmLCD, With Color Coded LED Indicator |
|
LED Indicator |
Green LED represents a safe, air-dry state |
|
Yellow LED represents a borderline state |
|
|
Red LED represents a damp state |
|
|
Calibration |
Automatic |
|
Battery Indicator |
LowBatteryIndicator |
|
Data Output |
USB, RS-232, Bluetooth |
|
Operating Conditions |
Temperature: 0~50 %°C, Humidity: < 90 %RH |
|
Power Supply |
4 x 1.5V AAA Size (UM-4)Battery |
|
Dimensions |
Uint: 150 x 65 x 30 mm |
|
Sensor: 175 x 76 x 76 mm |
|
|
Weight |
690 g (Not Including Batteries) |
Standard Accessories:
1. Main Unit
2. Cup Sensor
3. Carrying Case
4. Operation Manual
Optional accessories:
1. USB, RS-232Cdata cable with software
2. Bluetooth data out put with software
