CM-8829H COATING THICKNESS GAUGE
Anticorrosion Coating Thickness Gauge
The F probes measure the thickness of non-magnetic materials (e.g. paint, plastic, porcelain enamel, copper, zinc, aluminium, chrome etc.) on materials of iron . often used to measure the thickness of galvanizing layer, lacquer layer, porcelain enamel layer, phosphide layer, copper tile, aluminium tile, some alloy tile, paper etc
Features:
* The F probes measure the thickness of non-magnetic materials on magnetic materials.
* Two measurement mode: Single and Continuous（Notice：Continuous mode is convenient to measure the
coating thickness of curved objects and tiny objects.）
* Metric/imperial system selectable.
* Manual or automatic shut down.
* Auto memory of calibration value, and auto recognize the substrate.
* Operation process have buzzing reminder, while no buzzing in continuous mode.
* Use “USB data output” and “RS-232 data output” to connect with PC.
* Provide “Bluetooth ™ data output” choice.
|
Operating Principle |
F Magnetic Induction |
|
Measuring Range |
0~15 mm |
|
Resolution |
0.01 mm/0.1 mm |
|
Min. Raius Workpiece |
F Type: convex 20 mm / concave 30 mm |
|
Min. Measuring Area |
16 mm |
|
Min. Sample Thickness |
0.3 mm |
|
Accuracy |
± 1~3%n or ± 0.1 mm |
|
Auto Power Off |
|
|
Metric / Imperial |
Convertible |
|
BatteryIndicator |
LowBatteryIndicator |
|
Operating Conditions |
Temp. 0~40 °C, Humidity: 10~90 %RH |
|
Power Supply |
4 x 1.5 V AAA (UM-4)Battery |
|
Dimensions |
126 x 65 x27 mm |
|
Weight |
210 g(Not Including Batteries) |
Standard Accessories:
1. Main Unit
2. Probe (F Type)
3. Calibration Base Set (F Type) CTG-BS
4. Calibration Foils CTG-CF (1 set, 4 pieces)
5. Carrying Case
6. Operation Manual
Optional accessories:
1. USB, RS-232Cdata cable with software
2. Bluetooth data out put with software
