HV-1000A MICROHARDNESS TESTER

Feature & Use

. Automatic turret switching between penetrator and objective lens

. Frictionless loadingshaft, high precision testing force

.Automatic testing process, no human operating error

. Precision conforms to GB/T 4340.2, ISO 6507-2 and ASTM E384

It can be used to determine the Vickers hardness of steel, non-ferrous metals, ceramics, treated layers of metal surface, and thehardness grads of carburized, nitrided and hardened layers of metals. It is also suitable to determine the Vickers hardness of micro and super thin parts.



Specifications：

    Hardness measuring range: 5-3000HV

    Test force: 0.09807, 0.2452, 0.4904, 0.9807, 1.961, 2.942, 4.904, 9.807N

                    (10, 25, 50, 100, 200, 300, 500, 1000gf)

    Hardness scale: HV0.01, HV0.025, HV0.05, HV0.1, HV0.2, HV0.3, HV0.5, HV1

    Magnifications of the measuring system: 400X(measuring), 100X(observing)

    Min. scale value of the optical micrometer: 0.025μm

    Measuring range: 200μm

    Max. height of test piece: 75mm

    Depth of throat: 110mm

    Power supply: 220V AC or 110V AC, 50 or 60Hz

    Dimensions: 470 x 320 x 500mm

    Weight: approx. 40kg



Standard accessories:

    Coordinate anvil: 1 pc.

    (Table size: 100 x 100mm, travel: 25 x 25mm, grade division of micrometer head: 0.01mm)

    Thin shaft anvil (Ø0.3- Ø5mm): 1 pc.

    Thin plate anvil: 1 pc.

    Flat nose pliers: 1 pc.

    Large V-notch anvil: 1 pc.

    Small V-notch anvil: 1 pc.

Diamond pyramid penetrator: 1 pc.

Micro-Vickers standardized block: 2 pcs.



Optional accessories:

Knoop penetrator

CCD camera and image processing system
