1. Test Forces

(0.098, 0.246, 0.49, 0.98, 1.96, 2.94, 4.90, 9.80) N
(10, 25, 50, 100, 200, 300, 500, 1000) gf

2.Carriage Control: automatic ( loading / holding-up of the load / unloading )

3. Amplification of the Microscope: 200 ×、 400 ×

4. Dwell Time of the Test Force: (5-60)s

5. Min. Graduation Value of the Testing Drum Wheel: 0.0625um

6. Testing Field: 1HV—2967HV

7. Dimension of the XY Table: 100 ×100 mm

8. Movement Field of the XY Table: 25 ×25mm

9. Max. height of the specimen :100mm

10. Max. width of the specimen :98mm

11. Output : installed with a printer and a RS232 serial interface

12. Light source : cold light source

13. Power Supply : 110V/220V,60/50Hz

14. Dimension: (480 × 305 × 545)mm

15. Weight:30Kg

Usage Range:

● Ferrous metals, non-ferrous metals, IC thin sections, coatings, ply-metals;

● Glass, ceramics, agate, precious stones;

● Hardness testing such as that on the depth and the trapezium of the carbonized layers and quench hardened layers.

XY-stage test table

Thin specimen test table

Fork-shaped test table

Fine wire test table

Adjustable screw

10×Digital Micro Lens

Micro Vickers hardness blocks (high medium)

Gradienter
