BZQG-65 Automatic Metallographic Sample Cutting Machine

The machine is a combination of manual / PLC control and automatical control as one of the metallographic sample cutting machines, with very high reliability and control ability. Features: (i) manual and automatic free conversion, (ii) the touch screen displays a variety of cutting data, (iii) precise positioning, (iv) cut cutting, absolute cutting, incremental cutting-three functions cutting way, in order to make the cutting room easy to clean and ensure the spindle motor’s safety, we use mechanical and electrical separation. The cutting room security guard cover selected transparent plexiglass material. The cutting indoor room installed ventilation fan to increase the working room light and clarity. The design is more humane, using man-machine engineering principles. The device is equipped with a cooling water tank designed for the storage of coolant. Cutting sample of rock, ceramic, diamond grinding wheel must be used before cutting. BZQG-65 features: low noise, easy to operate, beautiful appearance, safe to use, and is one of the necessary equipment for laboratory sample preparation.

Main parameters:

1. Manual / electric can choose freely.

2. Cutting feed speed: 3 mm / min, 5 mm / min, 8 mm / min (user may modify the set speed according to requirement)

3. Y-axis maximum travel distance：235mm。

4. Z axis maximum travel distance：35mm (砍式cut style)

5. Maximum cutting diameter：65mm

6. Cooling water tank capacity：70L

7. Motor：2.2kw，speed：2800 r/min；

8. Power：380V，50HZ

9. Dimension：860×780×1330mm

10. The body forms：vertical

11. Weight：～110kg

12. Three-phase five-wire 380V 50HZ：A,B,C,N,PE
