HRM-45DT rockwell hardometer
Description:
Main Features
This series of hardness testers features high measuring accuracy, veliable performance and applicable to wide fields. By adopting the motor driven automatic loading and unloading technique, that thoroughly eliminates human error in those operations.
Model HRM-45DT serves to determine the superficial Rockwell Hardness of hard metals, carburized, nitrided layers, and other chemical freating layers, it is also used to for hardness test of thiner pieces.
Technical Features and Standard Accessories
|
Initial Testing Force |
29.42N(3KG) |
|
All Testing Force |
147.1N(15kg),294.2N(30kg),441.3N(45kg) |
|
Indication of Hardness Value |
Dial |
|
Duration Time |
2-60S |
|
Max Height of Specimen |
170mm |
|
Max Width of Specimen |
165mm |
|
Dimensions |
520x215x700mm |
|
Net Weight |
73kg |
|
Power Supply |
Ac220±5%,50-60Hz |
|
Standard Accessories |
Standard Superficial Rockwell hardness block Diamond Rockwell Hardness indenter, Φ1.5875mmBall indenter ,Large Testing Table, Medium Testing Table and V-shaped Table, Weight (a,b,c), Lever, Power Cord |
