photo contact tachometer DT-2856
Used to measure rotative velocity, surface speed, frequency of motor. Applicable to the product departments of motor, fan, paper-product, chemical fiber, washing-machine, automobile, airplane, steamer etc.
Features:
* Multifunctional, one instrument combines PHOTO TACH.(RPM) & CONTACT TACH. (RPM).
* Digital display with no guessing errors.
* Wide measuring range and high resolution.
* The last value / max. value / min. value will be automatically stored in memory.
* The use of durable, long-lasting components, including a strong, light weight ABS-plastic housing assures elegant shape and ease of use.
|
Measuring Range |
Laser |
2.5 ~ 99,999 r / min |
|
Contact |
0.5 ~ 19,999 r / min |
|
|
Resolution |
0.1 r / min (0.5 ~ 999.9 r / min) 1 r / min (Over 1000 r / min ) |
|
|
Accuracy |
± (0.05% n + 1 d) |
|
|
Sampling Time |
1.0 s （Over 60 r / min ） |
|
|
TestRangeSelect |
Automation |
|
|
Memory |
Max / Min / Last Value |
|
|
Time Base |
Quartz Crystal |
|
|
Laser Tach Detecting Distance |
50 ~150 mm/ 2 ~ 6 inch (Typical), Max.300 mm/ 12 inch |
|
|
Power Consumption |
90 mA （Testing） |
|
|
Operating Temperature |
0 ~50 °C |
|
|
Power Supply |
4 x 1.5 V AA size (UM-3) battery |
|
|
Dimensions |
215 x 74 x32 mm |
|
|
Weight |
200 g（Including Batteries） |
|
Standard Accessories :
1. Main Unit ...............................1pc.
2. Carrying Case(B01) ...........1pc.
3. Operation manual ...............1pc.
4. Reflective tape350mm .......2pc.
5. Cone Adapter(AS35A) .......1pc.
6. Funnel Adapter(AS35B).......1pc.
