Application and Feature of Grinding-Polishing Machine

The grinding-polishing machine is a double-disc desktop, applicable to rough grinding, accurate grinding and polishing of metallographic sample. The machine has a microprocessor control system, with a speed of 50-600rpm, thus widening its application. The machine has dual control systems, operated by two people simultaneously. The machine has a cooling device to cool the sample during grinding and polishing, thus preventing the damage of the metallographic structure caused by overheat of the sample. The machine, easy to use, safe and reliable, is an ideal sample preparation equipment for the labs of plants, research institutes and universities and colleges.

Technical Parameters

1. Working Voltage: 220V 50HZ

2. Diameter of Grinding-Polishing Disc: Φ203mm (custom-made Φ250mm)

3. Speed: 50-600rpm (stepless speed change) or 150rpm and 300rpm (two-step constant speed)

4. Diameter of Abrasive Paper: 200mm (custom-made Φ250mm)

5. Motor: YSS6324, 250W

6. Dimensions: 750mm×700mm×270mm

7. Weight: 55kg
