Feature & Use:

Full automatic closed loop control system

Electronic loading system

Automatic test process, no human operating error

Large LCD display of testing process, easy operation

Precision conforms to GB/T 231.2, ISO 6506-2 and ASTM E10

It's suitable to determine the Brinell hardness of unquenched steel, cast iron, non-ferrous metals and soft bearing alloys, etc.

Specifications

Measuring range: 4-650HBW

Test force: 980.7, 1225.9, 1838.8, 2451.8, 4903.5, 7355.3, 9807, 14710.5, 29421Ｎ (100, 125, 187.5, 250, 500, 750, 1000, 1500, 3000kgf)

Max. height of test piece:280mm

Depth of throat:150mm

Power supply: 220V AC or 110V AC, 50 or 60Hz

Dimensions: 570 x 330 x910mm

Weight: Approx.290kg　

Standard accessories

Large flat anvil: 1 pc.

Small flat anvil: 1 pc.

V-notch anvil: 1 pc.

Tungsten carbide ball penetrator: Φ2.5, Φ5, Φ10mm, 1 pc. each

Brinell standardized block: 2 pcs.

20X Readout microscope: 1 pc.
