Feature & Use |
|
Small volume, convenient for carrying, easy operation |
|
The measured Leeb hardness value can be converted into Brinell, Rockwell, Vickers and Shore hardness, etc. |
|
Precision conforms to GB/T 17394, JB/T 9378 |
|
It's suitable to determinethe Leeb hardness of ferrous and non-ferrous metal precisely. |
|
Specifications |
|
Power supply: 6.0V DC |
|
Working temperature: 1-40 °C |
|
Dimensions: 268 x 86 x 47mm |
|
Weight: approx. 0.67kg |
|
Standard accessories |
|
Small positioner: 1 pc. |
|
Binder: 1 bottle |
|
Leeb standardized block: 1 pc. |
|
Charger: 1 pc. |
Specifications of impact device
|
Type |
D |
DC |
D+15 |
G |
|
Specifications |
||||
|
Measuring range |
330-890HL |
330-890HL |
346-890HL |
300-650HLG |
|
Impact capacity |
11Nmm |
11Nmm |
11Nmm |
90Nmm |
|
Dimensions |
Φ20x150mm |
Φ20x85mm |
Φ20x165mm |
Φ20x250mm |
|
Testing direction |
Arbitrary |
|||
|
Weight |
75g |
50g |
80g |
250g |
|
Mass of impact body |
5.5g |
5.5g |
5.5g |
20g |
|
Diameter of tungsten carbide ball |
3mm |
3mm |
3mm |
5mm |
|
Application range |
Basic type, suitable for most of hardness tests. |
Suitable for hardnessmeasuring of inner holes and small space. |
Suitable for determining hardness of tooth face and slots, etc. |
Suitable for hardnessmeasuring of steel, cast steel, gray castiron, nodular cast ironand non-ferrous metals. |
