Feature & Use

Automatic tracking and testing, no test error caused by deformation of frame and work piece

The first test is effective

RS232 data interface

It's suitable to determine the Rockwell & Superficial Rockwell hardness of ferrous metals, alloy steel and hard alloy, as well as treated layers of metal surface, such as carburized layer, nitrided layer and electroplated coating, etc. It's especially suitable to determine heterotypic work piece.

Specifications

Test force: Rockwell 588.4, 980.7, 1471N (60, 100, 150kgf)

Superficial Rockwell 147.1, 294.2, 441.3N (15, 30, 45kgf)

Measuring scale: HRA, HRB, HRC, HRD, HRN, HRT  (Scales of E, F, G, H, K are optional)

Unit of display: 0.1HR

Moving range of measuring head:50mm

Output: built-in RS232 interface

Max. height of test piece:170mm

Depth of throat:150mm

Dimensions:  535 x 220 x910 mm

Power supply: 220V AC or 110V AC, 50 or 60Hz

Weight: approx.100kg

Standard accessories

Large flat anvil: 1 pc.

Small flat anvil: 1 pc.

V-notch anvil: 1 pc.

Diamond cone penetrator: 1 pc.

1/16" steel ball penetrator: 1 pc.

Rockwell standardized block: 5 pcs.

Superficial Rockwell standardized block: 6 pcs.
