MY-1 Spectrum of Abrasive Belt Grinding Machine

Grinding is the necessary working procedure before spectral measurement in the preparation of spectrum specimen. MY-1 Spectrum of Abrasive Belt Grinding Machine is the new product developed according to numerous market research, many-sided service conditions and merits of each grinding machine.

Operating principle of MY-1 Spectrum of Abrasive Belt Grinding Machine: There is a big rolling drum with rubber on the main axle of the electric motor. It drivers the slave drum by abrasive band. The abrasive band moves straightly .The sample can be grinded to satisfy the spectral measurement demand on the abrasive band.

Main parameters：

Center Distance of Rolling Drum：310mm

Width of Abrasive Paper：100mm

Length of Abrasive Paper：920mm

Platen Speed：1400 r/min     480m/m

Electromotor：Y801-4，0.55KW，380V，50Hz

Total Dimension：470×480×230mm

Net Weight：55Kg
