Ultrasonic Thickness TesterMIC-L342

Measuring range(mm)

0.75 ~ 300

Resolution(mm)

0.01

Accuracy(mm)

±（1%H+0.1）

Velocity range(m/s)

1000 ~ 9999

Memory

2000 groups

Velocity measurement

√

English Menu

√

LED backlight

√

Operating temperature

-10℃~60℃

Dampness

20%~90%

Dimensions

230×86×46mm

Power supply

6V rechargeable NI-MH battery

Weight

400g

Optional Accessories

Probes，Couplant，Paper for printer,Charger

Standard Delivery

Probes，Couplant

Function & Feature:

Built-in rapid thermal printer.

Automatic proofreading zero, on the system error correction.

Data transmission: RS232 interface, can be connected to the PC.

The unit of measurement, metric, inch optional.

A two-point calibration, can improve the accuracy of measurement

Rechargeable NI-MH battery.

Battery information indicates the rest capacity of the battery,Auto sleep and auto power off function to conserve

battery life.

Display: LCD with LED backlight .The brightness and the contrast of the LCD is adjustable. And thickness

value, coupling condition, power state, CAL calibration state, sound velocity.

Able to measure the ultrasonic velocity in turn if the thickness value is known in order to improve the

measurement precision.

A two-point calibration, can improve the accuracy of measurement.

Nonlinear correction, automatic compensation, in order to improve the measurement accuracy.

Alarm function: setting the measurement limit and alarming for the results beyond the limit.

Application Fields:

Widely used in petroleum, chemical industry, metallurgy, shipbuilding, aerospace and other fields.

Measuring Material:

Adapted to measure the thickness of good conductor for ultrasonic, such as metal(steel, cast iron, aluminum,

copper), plastic, ceramic, glass, glass fiber and so on.
