Coating Thickness Gauge MIC-L210

Coating Thickness Gauge MIC-L210

Operating principle

Magnetic induction (F1)

Measuring range

0~1250μm

Accuracy

±[1~3%)H+1]

Low range resolution

0.1μm

Min curvature of the min area (mm)

Convex1.5

Concave9

Diameter of the min area (mm)

Φ7

Critical thickness of substrate (mm)

0.5

Operating temperature

0~40

Magnetic field

No strong magnetic field environment

Memory

500 Groups

Dimensions

115×70×30mm

Weight

152g

Power supply

AAA Alkaline battery

Standard configuration

Unit Probe Matrix,5 specimens (50m100m200m500m1000m)2 AAA Batteries.

Function & Feature

English menu.

With settled probe.

Two methods of power off: Manual & Automatically.

Show battery information in real time.

Limit settings: alarm if one of the measurement data is beyond of the limits.

Deleting function: You can delete one of the doubtful data and you can also delete all of data in the memory to prepare for new measurement.

Saving function: capable of 500 sets of measurement value.

Five statistical data: Mean Value, Maximum Value, Minimum Value, Measurement, Standard Deviation.

Application Fields:

Coating thickness gauge is mainly used for measuring hull, oil and gas pipeline, high pressure vessel and boiler wall thickness as well as a variety of plate thickness, can be measured material is a delegate with steel metal materials, can be plastic, nylon and other non-metallic materials.

Measuring Material:

Non magnetic coatings on magnetic substrates (such as aluminum, chromium, copper, zinc, tin, rubber, paint on the steel, iron, alloy and magnetic steel).
