VMC-606 Vibration calibrator
The Vibration Calibrator is a small, self-contained handheld shaker designed for quick and easy check-ing of accelerometers, vibration monitoring systems and recording systems. Providing a known and cont-rolled RMS vibration for verification of acceleromet-ers weighing up to150g.
Features:
*Operates at 159.2 Hz.
*10 mm/s RMS velocity output.
*Drives vibration sensors up to150g.
*CE compliant.
|
Operating Frequency |
159.2 Hz ± 0.5 % |
|
Acceleration Output |
10 m/s² (RMS) ± 3% |
|
Velocity Output |
10 mm/s (RMS) ± 3% |
|
Displacement Output |
10 um (RMS) ± 3% |
|
Transverse Output |
< 5% |
|
Distortion |
< 3% |
|
Maximum Load |
150 g |
|
Ramp-Up Time |
< 3 Seconds |
|
Operating Conditions |
Temperature : -10~40 °C Humidity : < 85 %RH |
|
InternalBattery |
1x9V 6F22 |
|
Size (Diameter x Height) |
56 mmx200 mm |
|
Weight (with batteries) |
900 g |
Standard Accessories:
1. Main Unit
2. Carrying Case
3. Manual Book
