PH/ORP-2000 Controller
Used for applications such as water treatment and monitoring, galvanic-decontamination, chemical processing, food processing, clean or wastewater control and neutralization processes.
Features:
Though the construction of the pH / ORP Controller complies with safety regulations currently in force, improper use could lead to hazards for the user or a third-party. Therefore, the operating instructions must be read and understood by the persons involved before work is started with the pH / ORP Controller.
|
Range |
0 ~ 14 pH / 1 mV、-1000 ~ 1000 mV |
|
Accuracy |
0.01 pH、1 mV |
|
Display |
LCD |
|
Output |
Optional DC 4 ~20 mA Max. Load 1 K |
|
Control Action |
ON / OFF |
|
Relay Current |
220 VAC Max.3 A or 600 VA |
|
Control Set |
2 ( High, Low ) |
|
Operating Temperature |
0 ~60 °C |
|
Power Supply |
220 VAC 50 Hz or 110 VAC 60 Hz |
|
Dimensions |
92 mm（H）-92 mm（W）-110 mm（D） |
|
Weight |
0.2 Kg |
Standard Accessories:
1. Main Unit
2. Carrying Case (B03)
3. Operation Manual
Optional Accessories:
|
Optional Probes |
|
|
Model Number |
Cases |
|
PH-200 |
Common Industry |
|
PH-201 |
Highly Polluted Process and Waste Water |
|
PH-202 |
Anti-HF Electrode |
|
PH-203 |
Cases of High Pressure or Leavening |
|
ORP-201 |
ORP Electrode |
