DT2350PA PB PC PD PE stroboscope
The Stroboscope is capable to provide image of single, two or multiple stillness for the vibration object, rapidly rolling object or a periodic motion object, and can also use to observe the movement tracks.
Features:
* Digital display gives exact reading with no guessing or errors; Wide measuring range and high resolution.
* Automatic stop flashing to save electricity and improve flash tube lifetime.
* Internal / external triggering fast conversion; x2 and ÷2 button for fast adjustment.
* Use photoelectric signal while external triggering, achieve automatic tracking function of the pattern.
* Use microcomputer technology, emerging technologies, anti-jamming technique and other advanced technology, it can measure the rotative velocity without contacting the object.
|
Display |
5 Digits10 mmLCD |
|
Measurement Range |
A：50 ~ 12,000 FPM B：50 ~ 40,000 FPM C：50 ~ 20,000 FPM D：50 ~ 30,000 FPM E：50 ~ 2,000 FPM （Fit for Print and Textile） |
|
Accuracy |
±（ 0.05% n + 1 d ） |
|
Resolution |
0.1 FPM（50 ~ 999.9 FPM ） 1 FPM（Over 1000 FPM ） |
|
Sampling Time |
0.3 Seconds |
|
Internal / External Triggering Conversion |
|
|
External Trigger Level |
3 ~ 24 V |
|
With ×2 ，÷2 for Fast Check |
|
|
H / L Range |
Flashing Light is much Brighter at Low Range than at High Range |
|
Flash Tube Life |
100 Million Times |
|
Regular Operating Conditions |
No Corrosive Gas and Electromagnetic Fields |
|
Operating Conditions |
Temperature: 0 ~40 °C Humidity: < 85 %RH |
|
Power Supply |
AC 220 V（Optional AC 110 V ） |
|
Power Consumption |
About 50 W |
|
Dimensions |
215 × 85 ×180 mm |
|
Weight |
About 1000 g |
Standard Accessories:
1. Main Unit
2. Carrying Case (B08)
3. Operation Manual
Optional Accessories:
1. Spare Flashing Tube
2. Rechargeable battery only for DT-2350PA / DT-2350PE
