QG-5A Metallographic Sample Cutting Machine

QG-5A multifunctional cutting machine is mainly used for cutting irregular general metallographic sample materials such as round cylinder and polygon and protruding platforms, etc. This machine adopts double-shells totally closed structure and double quick clamp organization. It can guarantee cutting under absolutely safe status, this machine equipped with front, back board, the thickness of sample can be changed arbitrarily, and the speed of entering is controllable. In order to avoid the sample organization burns because of being overheated in cutting, this machine is furnished with the strong cooling system, and can avoid little burn of the sample surface while cutting and falling, can increase the cutting section, improve the utilization ratio of cutting emery wheel slice; it has convenient advantages in operation, maintenance; it is the extremely good apparatus for cutting irregular sample materials.

Main parameters

Maximum Cutting Cross Section100×100 mm

Platen Speed2800r/min

Cutting Wheel Sizeф350×2.5×ф32mm

ElectromotorY112M-24KW380V50Hz

Total Dimension800×660×1380mm

Net Weight315Kg
