PW-1B Multifunctional Grinding and Polishing Machine

PW-1B tank multifunctional grinding and polishing machine is used for the grinding and polishing operation of lithofacies specimen and metallographic sample. No matter the sample materials of rock, mineral, ceramics, glass, ferrous metal and other silicate, it is extremely adaptable to coarse grinding, oil grinding, dry grinding, wet grinding, grinding and polishing, etc. The machine has the features of stable revolution can be regulated stepless, which can be optionally regulated in the scope of 50-1400 r/min. In order to prolong the service life and easy to maintain daily, the machine's pollution-collecting disc, covering and lid are all made of stainless steel materials. So it is an excellent equipment of metallographic and lithofacies sampling.

Main parameters

Grinding and Polishing Wheel Diameter230mm

Abrasive Paper Diameter230mm

Platen Speed50~1400r/minstepless

ElectromotorBY80 frequency conversion motortriphase 220V 050Hz

Total Dimension700×490×1040mm

Weight85kg
