HRMS-45 rockwell hardometer
Description:
HRMS-45 Digital Superficial Rockwell Hardness Tester adopts novel-designed large LCD screen to display, as well as menu structure. It mainly functions are as follows: 1. Selection of Rockwell hardness scales, 2. Exchange hardness values among hardness scales, 3. Output the results of hardness measurement with printer, 4. RS-232 hyper terminal setting is with good reliability, excellent operation and easy watching.
Usage Range:
Surface hardened steel, surface heat treating and chemical treating materials, copper, aluminum alloy sheet, zinc layers, chrome layers, tin layers, bearing steel, cold and hard casting parts, etc.
Technical Specifications:
|
Pre-load(kg) |
29.4N(3KG) |
|
Loads(kg) |
147,294,441N(15,30,45kg) |
|
Load holding time |
2-60S |
|
Readout |
Digital display |
|
Power supply |
Ac220±5% 50/60Hz |
|
Specimen Height |
170 |
|
Throat depth |
160 |
|
Dimensions |
500×150×750 |
|
Weight |
85kg |
|
Accessories |
Diamond Rockwell Indenter, Diameter 1.588 Hard Alloy Steel Ball Indenter, Large Testing Table, Medium Testing Table and V-shaped Testing table,HR30N and HR30T Hardness Blocks,RS-232 Interface, Power Cable, etc. |
