Feature & Use:
Automatic recognition for the type of impact device
Menu operation, easy and convenient
Automatic detecting the impacting direction
The setup can be be saved automatically
Dual-operation both by keys or touch screen
Automaticstorage for 800 groups of testing data
It's suitable to determinethe Leeb hardness
of ferrous and non-ferrous metals precisely.
Specifications
|
Measuring accuracy: ± 4 HLD |
|
Hardness repeatability: ± 4 HLD |
|
Measuring range: 170～960 HLD |
|
Testing direction: arbitrary |
|
Hardness conversion: HRC, HRB, HB, HV, HSD & tensile strength |
|
LCD display: 3.9" LCD, 240 x 320 pixels resolution (touch screen) |
|
Data storage: 800 groups |
|
Upper & lower limit range: same as measuring range |
|
Working voltage: 3.7V (lithium rechargeable battery) |
|
Working time: 4-8 hours |
|
Charging power: DC 5.5V/1A |
|
Continuous working time after one charging: about 30 hours (backlight not on) |
|
Working temperature:0 °C～+50°C |
|
Working humidity: 20%～85% |
|
Storage temperature:-30 °C～+70°C |
|
Working humidity: 5%～95% |
|
Dimensions: 180 x 90 x30mm |
|
Weight:350g(including impact device) |
|
Packing dimensions: 368 x 247 x87mm |
|
Total weight: Approx.5.5Kg |
|
Heatsensitive printer: |
|
Width of print paper: 57.5±0.5mm |
|
Diameter of paper roll: ≤30mm(Heatsensitive print paper) |
|
Printing speed:5cm/sec. (when power is enough) |
|
Printing resolution: 203dpi (8dot/mm) |
|
Working power supply: 650mAh 7.2V rechargeable NiMH |
|
Recharging power supply: DC 12V/1A |
|
Dimensions: 90 x 76 x36mm |
|
Weight:220g(not including paper roll) |
|
Working temperature:-20 °C～+50°C |
|
Working humidity: 20%～85% |
|
Storage temperature:-30 °C～+70°C |
|
Working humidity: 5%～95% |
|
Standard accessories |
|
Heatsensitive printer: 1 pc. |
|
D type impact device: 1 pc. |
|
Small support ring: 1 pc. |
|
Leeb standardized block: 1 pc. |
|
Charger: 1 pc. (For both main machine and printer) |
