Product Details: |
|
Specifications |
|
Impact device: Intergrated D type impact device |
|
Accuracy: Mean uncertainly 1% ( HRC=58 ) |
|
Power supply: 2 x 1.5V Dry battery |
|
Working temperature: 0-45 °C |
|
Dimensions: 170 x 68 x30mm |
|
Weight:250g |
|
Main features |
|
HL, HRC, HRB, HV, HS, HB values can be measured |
|
RS232 interface: connect with PC |
|
Automatically storing 510 groups of data with mean value and testing time display |
|
Automatically correct the deviated test data |
|
Measuring in all directions, easy operation |
|
Large LCD display with backlight |
|
Date and Time display |
|
Automatic power off after 5 minutes without operation |
|
Other types of impact devices including G, DC, D+15, C, E & DL can be connected outside. |
Material & Measuring range
|
Material |
HLD |
HB |
HRC |
HRB |
HV |
HS |
|
Steel/Cast Steel |
300-900 |
80-650 |
20-68 |
40-100 |
80-977 |
32-100 |
|
Alloy Tool Steel |
300-840 |
|
20-67 |
|
80-898 |
|
|
Stainless Steel |
300-800 |
85-655 |
20-62 |
46-100 |
85-802 |
|
|
Gray Cast Iron |
360-660 |
93-334 |
|
|
|
|
|
Spheroidal Iron |
400-600 |
131-387 |
|
|
|
|
|
Cast Aluminum |
180-560 |
30-159 |
|
|
|
|
|
Brass |
200-540 |
40-173 |
|
13-95 |
|
|
|
Bronze |
300-700 |
60-290 |
|
|
|
|
|
Wrought Copper |
|
|
|
|
|
|
|
Alloys |
200-700 |
45-315 |
|
|
|
|
