320HBS-3000DIGITAL DISPLAY BRINELL HARDNESS TESTER

Feature & Use:

Digital display of hardness value

Full automatic closed loop control system

Auto turret, electronic loading system

Automatic test process, no human operating error

Large LCD display of testing process, easy operation

Precision conforms to GB/T 231.2, ISO 6506-2 and ASTM E10

It's suitable to determine the Brinell hardness of unquenched steel, cast iron, non-ferrous metals and soft bearing alloys, etc.

Specifications

Measuring range: 4-650HBW

Test force: 980.7, 1225.9, 1838.8, 2451.8, 4903.5, 7355.3, 9807, 14710.5, 29421 (100, 125, 187.5, 250, 500, 750, 1000, 1500, 3000kgf)

Max. height of test piece:280mm

Depth of throat:150mm

Optical magnification: 20X, 40X

Power supply: 220V AC or 110V AC, 50 or 60Hz

Dimensions: 570 x 330 x910mm

Weight: Approx.320kg

Standard accessories

Large flat anvil: 1 pc.

Small flat anvil: 1 pc.

V-notch anvil: 1 pc.

Tungsten carbide ball penetrator: Φ2.5, Φ5, Φ10mm, 1 pc. each

Brinell standardized block: 2 pcs.
