Home > Ophthalmic EquipmentsSlit lamp microscope > MIC-SB6 slit lamp microscope

This series slit lamp produced by MIC TECH gives the wonderful optical and mechanical performance. Provide most clearly and stereoscopic images for ophthalmologist and optician.

Outstanding Optic Quality Ensure the Comfortable View

Precision Machining Makes the Smooth and Flexible Movement

Professional & Multi-functional Software But with simple humanized human-computer interface & easy operate

Have both image capturing function and video capturing function

Image processing for better Symptoms Diagnose

Backup patient data base easily to guarantee data safety

Highest Quality Images Captured Which Impressive Every User

Main Features

High definition professional DSLR,18Mpixel

Illumination system with concentric background light

High definition video function available, 25 frame per second

Professional software for saving patients' case

Professional image processing system

A special designed black cross in right eyepiece to synchronize the image sharpness in eyepiece and LCD. Ensure what you see, what you get.

Standard configuration

Slit Lamp + Beam Splitter & Camera Adaptor + Canon DSLR + LED Background Illumination System + Sensor for OD/OS Recognition + Multifunctional Software + Computer + PrinterFor output reports+Relevant Spare Part & Cables

Optional configuration

Integrated, fully synchronized flash

Technical parameter

Microscope Type

Parallel Galilean

Magnification changer

Revolving the drum

Eyepiece

12.5X

Total magnification

6X  10X  16X  25X  40X 10X  16X  25X  optional)

Diameter of Vision field

φ37  φ23  φ14  φ8.7  φ5.7(mm)

Pupil adjusting range

54 mm~82 mm

Diopter adjustment

-7D ~ +7D

Slit image width

0mm14mm continuous

Slit image length

1mm14mm continuous

Diameter of aperture

φ14mmφ10mmφ5mmφ3mmφ1mmφ0.2mm

Slit angle

0180 Rota table continuous

Illumination tilting

5101520 totally 4 step

Filter

Heat absorption, Grey, red free(Green), Cobalt blue

Illumination

12v, 30w halogen bulb

Fixation

Red LED 3.5V

Power

Input voltage  100~240V

Input frequency 48~62 Hz

Input power 60VA

Package  Dimension

740*650*450mm   total27kg  Carton
